An alternative to the 111044 tee fitting is the Woodpecker Dripper.
These are available in different flow rates and have supply line
pressure requirements. Consult with your sales representative to
determine which dripper and pump are best for your application.
Additionally, the 110402 2-Way manifold is needed to attach the drip
lines to the dripper.
As described in the previous procedure, measure and cut the drip
tubing. Two (2) lines are needed for each bucket.
Take a 110402 2-way manifold and attach it to a dripper fitting.
Repeat for all dripper fittings.
Attach the dripper lines to the 2-way manifolds.
Punch the holes in the supply line as previously described and install
the drippers. Grip the body of each dripper and gently pull up to seat
the fitting in the supply line. Continue with the next procedure.
1
5
14
Assembly Instructions
2
6
3
7
4
8
