Commissioning the CP 440
Creating a User Program for the Communication Processor
CP programming includes the implementation of the CP in the STEP 7 user program of your
CPU. Program your CP using the language editors of the STEP 7 software.
Further Information
A detailed description of programming with STEP 7 is contained in the
STEP 7
Commissioning the Physical Interface
If there is no communication with the partner device after configuration has been completed,
you should test the connection. To do this, proceed as follows:
1. What might be the possible cause:
– Is the polarity of the send/receive lines reversed?
– Are the default settings correct? Several defaults may have been set with different
– Missing or wrong terminating resistors?
– High byte and low byte mixed in the security word (e.g. CRC)?
2. How to proceed:
– First of all, use the manual to check the line connection:
– Carry out a setup test
3. Carry out the simplest setup possible:
– Connect only 2 nodes to each another
– If possible, use 2-wire cable (RS485)
– Use a short cable
– Terminating resistors are not required due to the short distance
– Send first in one direction and then in the other
58
www.gkbpx.com
manual.
polarity. The default settings may already be integrated in the device on a permanent
basis.
- Pin assignment
- Polarity
- Default settings
Point-to-point connection CP 440 Installation and Parameter Assignment
该文档是极速PDF编辑器生成，
如果想去掉该提示,请访问并下载：
http://www.jisupdfeditor.com/
Programming with
Manual, 09/2007, A5E00057742-03
