- Page 1 Edition 03/2024 RECYCLER GUIDE SIMATIC S7-1500 CPUs This document covers all variants in the range 6ES7515-2.N03-0AB0, 6ES7516-3.P03-0AB0, 6ES7511-1.L03-0AB0, and 6ES7513-1.M03-0AB0. Reference product: 6ES7515-2AN03-0AB0 support.industry.siemens.com...
- Page 2 About this guide Safety instructions SIMATIC Recommended tool S7-1500 Recycler Guide for S7-1500 CPUs Disassembly instructions (6ES7515-2.N03-0AB0, 6ES7516-3.P03-0AB0, Explanation of substances 6ES7511-1.L03-0AB0, and and components 6ES7513-1.M03-0AB0) Received material fractions Product Information Disclaimer of liability 03/2024 A5E53705324-AA...
- Page 3 Note the following: WARNING Siemens products may only be used for the applications described in the catalog and in the relevant technical documentation. If products and components from other manufacturers are used, these must be recommended or approved by Siemens. Proper transport, storage, installation, assembly, commissioning, operation and maintenance are required to ensure that the products operate safely and without any problems.
-
Page 4: Table Of Contents
Table of contents About this guide..........................Safety instructions..........................Recommended tool..........................Disassembly instructions........................Explanation of substances and components..................13 Received material fractions........................ 14 Disclaimer of liability.......................... 15 Recycler Guide for S7-1500 CPUs (6ES7515-2.N03-0AB0, 6ES7516-3.P03-0AB0, 6ES7511-1.L03-0AB0, and 6ES7513-1.M03-0AB0) Product Information, 03/2024, A5E53705324-AA... -
Page 5: About This Guide
The Siemens recycler guide provides recyclers of electronic products with instructions on how to disassemble products safely in order to maximize resource recycling. This guide provide step-by-step disassembly instructions and material composition information to help recyclers direct fractions to the appropriate material recycler. -
Page 6: Safety Instructions
Safety instructions The recycler is responsible for independently evaluating all activities of its employees to perform or support the work and to ensure compliance with all applicable health and safety laws related to the work. This includes, but is not limited to, laws regarding the health and safety of all employees performing or assisting in that work. -
Page 7: Recommended Tool
Recommended tool To disassemble the product, we recommend using the following tool: Figure Flat-tip screwdriver Recycler Guide for S7-1500 CPUs (6ES7515-2.N03-0AB0, 6ES7516-3.P03-0AB0, 6ES7511-1.L03-0AB0, and 6ES7513-1.M03-0AB0) Product Information, 03/2024, A5E53705324-AA... -
Page 8: Disassembly Instructions
Disassembly instructions The following guide provides detailed information on how to disassemble the product at the end of its service life and on what materials you can collect and recycle. In doing so, you support the recycling economy. Components of the product Position Part Material... - Page 9 Disassembly instructions Disassembling the enclosure Follow these steps for disassembly: 1. Pull the front flap (4) up 90 degrees. Pull off the front flap. 2. Remove the display (3) with a flat-tip screwdriver. 3. To open the enclosure (1a, 1b), use a flat-tip screwdriver to press the snap locks on the top and bottom.
- Page 10 Disassembly instructions 4. Pull of the front enclosure (1b). Disassembling printed boards 1. Remove the assembled PCB (2a) by pulling it out of the rear enclosure (1a). 2. Remove the assembled PCB (2b) by pulling it out. Separate the spacer frame (1c) from the assembled PCB (2b) by prying open the snap lock with a flat-tip screwdriver and pulling the frame downwards.
- Page 11 Disassembly instructions 3. Use a flat-tip screwdriver to detach the assembled PCB (2c) by pressing the snap locks on the inside of the rear housing (1a). 4. Remove the assembled PCB (2c) by pressing with a flat-tip screwdriver to the inside of the enclosure (1a).
- Page 12 Disassembly instructions 5. Detach the assembled PCB (2d) from the front enclosure (1b) by pressing the snap locks with a flat-tip screwdriver. 6. Remove the assembled PCB (2d) from the enclosure. Recycler Guide for S7-1500 CPUs (6ES7515-2.N03-0AB0, 6ES7516-3.P03-0AB0, 6ES7511-1.L03-0AB0, and 6ES7513-1.M03-0AB0) Product Information, 03/2024, A5E53705324-AA...
-
Page 13: Explanation Of Substances And Components
2a, 2b, 2c, 2d Assembled PCB: Step 1, 4, 5, 6 Information on Directive 2012/19/EU In order to support the recycling economy, SIEMENS creates transparency that goes beyond the regulatory requirements. See the table for additional information on smaller PCBs or displays, as well as metal alloys containing elements that may be critical at the end of the service life, such as beryllium or lead. -
Page 14: Received Material Fractions
Received material fractions All results from this process must be managed, handled, and disposed of in accordance with applicable waste laws and regulations including, but not limited to, the Waste Framework Directive and its national legislation in Europe and worldwide. The following table contains the main material fractions, but is not exhaustive. -
Page 15: Disclaimer Of Liability
Reuse of dismantled components is not permissible. Siemens therefore assumes no liability for errors or consequences that may result from the use of this information to the greatest possible legal extent. Please note that the data in this recycler guide cannot be compared to data calculated based on product category rules (PCRs) other than the above standards.
