i1000s Calibration

Change #1

On page 8, Table 4, under Recommended Model,
Replace:
Digital Multimeter
With:
Digital Multimeter
Delete the following from Table 4,
AC/DC Shunt
Replace the entire Phase Shift section, Table 5 and Figure 3 with the following:

Phase Shift Test

To check Phase Shift performance, set up the equipment as shown in Figure 3.
1. Center the Current Probe around the coil.
2. Set the calibrator output to 1V (phase meter reference input), 1A and 50 Hz, per step 1 of Table 5.

Performance Test Steps.

3. Verify that the phase meter reading is within the "Phase in Deg" limits of Table 5.
Coil
Step
1 50 turn
2 50 turn
3 50 turn
4 50 turn* 1 mV/A
5 1 turn
6 50 turn
7 50 turn
8 1 turn
9 1 turn
10 1 turn
* 700 A/ 50 Hz in 1 mV/A range has a TUR of 3.3
4. Continuing to use 1V as the phase meter reference input, set the calibrator output for the remaining
steps listed in Table 5. Steps 2 and 8 do not require phase tests.
5. Verify that the phase meter readings meet the "Phase in Deg" limits for each step.
7/01
Hp 3458A or equivalent
Agilant 3458A or equivalent
IET Labs-DCCS-200

Table 5. Performance Test Steps

5500A
5520A
Range Output I. Prim.
1 mV/A 1 A 50.0 A
1 mV/A 2 A 100 A
1 mV/A 4 A 200 A
14 A 700 A
10 mV/A 5 A N/A
10 mV/A 0.4 A 20 A
10 mV/A 2 A 100 A
100 mV/A 0.50 A N/A
100 mV/A 2.00 A N/A
100 mV/A 10 A N/A
0.1e - 0.1% non-inductive
Coil
Freq.
Min.
50 Hz 48.5
400 Hz 98.0
60 Hz 197.0
50 Hz 692.0
50 Hz 44.0
50 Hz 191.0
50 Hz 975.0
50 Hz 38.5
50 Hz 184.0
50 Hz 960.0
1
Manual Supplement
i1000s
mV Output Phase in Deg.
Max. Min.
51.5 -3.0
102.0 N/A
203.0 -2.0
708.0 -2.0
56.0 -15.0
209.0 -10.0
1025.0 -10.0
61.5 N/A
216.0 -15.0
1040.0 -15.0
Max.
3.0
N/A
2.0
2.0
15.0
10.0
10.0
N/A
15.0
15.0
