i1000s
AC Current Probe for Oscilloscopes
Users Manual
PN 1574925
June 2000 Rev. 3, 3/17
© 2000-2017 Fluke Corporation. All rights reserved.
Specifications are subject to change without notification.
All product names are trademarks of their respective companies.
PowerMeterStore
1.800.561.8187
www.
.ca
for Power Metering products online at:

Advertisement

Table of Contents
loading

Related Manuals for Fluke i1000s

Summary of Contents for Fluke i1000s

  • Page 1 AC Current Probe for Oscilloscopes Users Manual PN 1574925 June 2000 Rev. 3, 3/17 © 2000-2017 Fluke Corporation. All rights reserved. Specifications are subject to change without notification. All product names are trademarks of their respective companies. PowerMeterStore 1.800.561.8187 www.
  • Page 2 LIMITED WARRANTY AND LIMITATION OF LIABILITY Each Fluke product is warranted to be free from defects in material and work- manship under normal use and service. The warranty period is one year and begins on the date of shipment. Parts, product repairs, and services are war- ranted for 90 days.

  • Page 3: Table Of Contents

    Typical Response Curves ............8 Operation ................... 11 Measurement Considerations ............. 13 Maintenance ................13 Cleaning and Storage ............. 13 Replacement Parts ..............14 Service ..................14 Contacting Fluke ................ 14 PowerMeterStore 1.800.561.8187 www. for Power Metering products online at:...
  • Page 4 Input Ranges and Accuracy ............. 6 Maximum Phase Shift ............. 6 List of Figures Figure Title Page i1000s AC Current Probe ............2 Typical Response Curves ............8 ScopeMeter Setups ..............12 PowerMeterStore 1.800.561.8187 www. for Power Metering products online at:...

  • Page 5: Introduction

    Fluke i1000s AC Current Probe Introduction The Fluke i1000s is a clamp-on ac current probe designed to expand oscilloscope applications in industrial and power environments. The Current Probe (shown in Figure 1) provides the following features: • Ideal for measuring distorted current waveforms and harmonics.

  • Page 6: Box Contents

    Users Manual Tactile Barrier aef01f.eps Figure 1. i1000s AC Current Probe Box Contents The shipping container includes the probe, this users manual, a Quick Reference Card, and a product registration card. Safety Information Read the following safety information carefully before attempting to operate or service the Current Probe.
  • Page 7 AC Current Probe Safety Information Warning • To avoid injury and ensure safe operation of the probe, follow all safety precautions detailed in this manual. • Never use the probe on circuits rated higher than 600 V in measurement category III (CAT III). Use extreme caution when clamping around uninsulated conductors or bus bars.

  • Page 8: Instrument Compatibility

    47 pF. To achieve the stated accuracy, use the i1000s with an oscilloscope having an accuracy of ± 2 % or better. The i1000s may be used with digital multimeters (DMMs) if a BNC to banana jack adapter is used.

  • Page 9: Electrical Specifications

    AC Current Probe Electrical Specifications Electrical Specifications Current Range: 100 mA to 1000 A ac rms (2000 A instantaneous peak). Warning To avoid potential thermal burns from the jaws when measuring currents equal to or greater than 800 A ac rms in the ambient temperature range of 30 to 50°...

  • Page 10: Input Ranges And Accuracy

    Users Manual Emissions that exceed the levels required by CISPR 11 can occur when the equipment is connected to a test object. Korea (KCC) ....Class A Equipment (Industrial Broadcasting & Communication Equipment) Class A: Equipment meets requirements for industrial electromagnetic wave equipment and the seller or user should take notice of it.

  • Page 11: Mechanical Specifications

    AC Current Probe Mechanical Specifications Working Voltage (Clamp jaws to Ground): 600 V ac rms on Measurement Category III, Pollution Degree 2 circuits per EN/IEC 61010-1 and EN/IEC 61010-2-032. Float Voltage (Output cable and connector to Ground): 600 V ac rms on Measurement Category III, Pollution Degree 2 circuits per EN/IEC 61010-1 and EN/IEC 61010-2-032.

  • Page 12: Typical Response Curves

    Users Manual Typical Response Curves Typical response curves are shown in Figure 2. 1 mV/A Range 1.00 0.00 -1.00 -2.00 -3.00 @ 10 A -4.00 @ 50 A -5.00 1000 10,000 100,000 Frequency (Hz) 5.00 0.00 -5.00 -10.00 -15.00 -20.00...
  • Page 13 AC Current Probe Typical Response Curves 10 mV/A Range 5.00 0.00 -5.00 -10.00 -15.00 -20.00 @ 1 A -25.00 @ 5 A -30.00 1000 10,000 100,000 Frequency (Hz) 10.00 0.00 -10.00 -20.00 -30.00 -40.00 -50.00 @ 1 A -60.00 @ 5 A -70.00 1000 10,000...
  • Page 14 Users Manual 100 mV/A Range 5.00 0.00 -5.00 -10.00 -15.00 -20.00 -25.00 -30.00 -35.00 @ 0.1 A -40.00 @ 0.5 A -45.00 1000 10,000 100,000 Frequency (Hz) 40.00 30.00 20.00 10.00 0.00 -10.00 -20.00 -30.00 @ 0.1 A -40.00 @ 0.5 A...

  • Page 15: Operation

    Operation Operation Use the following procedure to make a measurement: 1. Connect the i1000s Current Probe to the desired input channel on the oscilloscope. 2. On the Current Probe, select the least sensitive range (1 mV/A). See Figure 1 for selector switch location.

  • Page 16: Scopemeter Setups

    Users Manual 1000 CHANNEL A aef02f.eps Figure 3. ScopeMeter Setups PowerMeterStore 1.800.561.8187 www. for Power Metering products online at:...

  • Page 17: Measurement Considerations

    AC Current Probe Measurement Considerations Measurement Considerations Observe the following guidelines for positioning the Current Probe jaws: • Carefully move the probe to center the conductor inside the jaws. • Make sure the probe is perpendicular to the conductor. • If possible, avoid measurements close to other current-carrying conductors.

  • Page 18: Replacement Parts

    Fluke i1000s Calibration Manual: 1574933 Service For service, pack the Current Probe securely in its original shipping container and forward it, postage paid, to the nearest service. Include a description of the malfunction. Fluke assumes no responsibility for damage in transit. PowerMeterStore 1.800.561.8187 www.
