1.7 Additional information
The aim of these instructions is to guarantee people safety and proper use of the transfer system. If
you wish to use the transfer system in any other conditions, don't hesitate to contact us.
More information is available on
http://elcom-automation.com/transfers/documentation
2 TECHNICAL CARACTERISTICS
- Maximum weight on workpiece carrier : 10 kg (except workpiece carrier)
- Maximum weight accumulation on stopper: 50 kg for a maximum stretch of 3 meters.
- Electric tension alimentation for motors: Direct 24 V
- Power consumption by motors :
(C= load in kilograms)
Installed power for this equipment : 220 V - 150 W
- Emission sonore : < 80 dB
- Module weight : See the catalog « Transfert linéaire modulaire & convoyeurs à bandes ».
http://www.elcom.fr/transferts/documentation
Warning ! Every overload can lead to advanced damage for the belt or any other
element.
I02-244 User & maintenance manual
of
TLM2000 ITS 24 V
elcom
website:
C = 0 (no load) → P < 10W
C = 35Kg → 20W < P < 50W
Version 03
(translation of the original manual)
Page 3 of 32
