Take off the pulley Rep 5 blocked by a screw M4 Rep 6
❑
Take off the drive motor fixed by 4 screws CHC M5 Rep 11
❑
5
To reassemble, please follow the instructions in reverse order.
I02-244 User & maintenance manual
of
TLM2000 ITS 24 V
6
11
Version 03
(translation of the original manual)
Page 15 of 32
