Mocka Eclipse Four Drawer Assembly Instructions Manual page 9

Eclipse Four Drawer
Assembly Instructions
15
Drawers x4
O
O
3 15
3 13
x2 /
Attach panels [15], [16], [17] and [19] together as shown using 20x screws (O).
Tighten with a screwdriver.
mocka.co.nz | mocka.com.au | PO BOX 6171, Maroochydore, QLD, 4558
O
3 19
O
3 14
x2
16
E
O
3 16
Attach slide rail (I) and slide rail (H) to the underside of the side
panels [15] and [16] as shown. Secure with 16x screws (E) and
tighten with a screwdriver.
Drawers x4
E
3 16
I
3 13 3 14
x2 / x2
3 15
H
E
E
9
