Mocka Eclipse Four Drawer Assembly Instructions Manual page 7

Eclipse Four Drawer
Assembly Instructions
11
Attach panels [11] to panel [2] as shown using 6x screws (O).
Tighten with a screwdriver.
mocka.co.nz | mocka.com.au | PO BOX 6171, Maroochydore, QLD, 4558
O
3 11
2
O
O
O
O
11
O
O
12
Drawers x4
C
C
C
C
3 14
3 13
x2
Insert 20x bolts (C) into panels [13] and [14]. Tighten with a screwdriver.
C
C
C
x2
C
C
C
7
