Eclipse Four Drawer
Assembly Instructions
17
Drawers x4
M
3 14
x2
N
M
3 13
x2
Attach 4x handles (M) to panels [13] and [14] and secure with 8x
handle screws (N). Tighten with a screwdriver.
mocka.co.nz | mocka.com.au | PO BOX 6171, Maroochydore, QLD, 4558
Tighten the
screws 90%..
N
N
Tighten the
screws 90%..
N
18
3 13
3 14
Insert the assembled drawers into the corresponding compartments
as shown. Ensure the drawers slide easily along the rails.
3 13
3 14
