Mocka Eclipse Four Drawer Assembly Instructions Manual page 5

Eclipse Four Drawer
Assembly Instructions
7
A
A
A
D
D
3
Attach panel [1] to panels [3], [4], [5] and [7] with 6x dowels (A) and
secure with 5x locking nuts (D) and 3x screws (B). Tighten with a
screwdriver.
mocka.co.nz | mocka.com.au | PO BOX 6171, Maroochydore, QLD, 4558
1
A
A
A
D
7
D
D
4
B
3 5
B
B
8
3
Slide panel [9] down along the grooves between the panels [3]
and [4] to form the back of the unit as shown.
4
9
5
