5. Implementing a presence simulation
Using the actions, you can create scenes that are called according to time, event or user control. Actions can be combined into a group for a presence simulation and
given a trigger time. Two examples of applications for summer and winter are described below.
5.1 Create actions
The actions serve to switch/move the lighting and blinds at 20:50 with a time delay of ± 30 minutes during the summer holiday. The creation of the first action is
explained below using the ambient lighting in the living room. Further actions can be configured in addition.
1.
Create the
Ambience
action on the
Actions
tab and select the
Time
schedule
action type.
Program the
Timer
[1], e.g.:
Friday to Sunday: 20:50
Random delay: 30 minutes
Living room
2.
Allocate the action to a room (area).
2
1
3.
Add the respective
functions
[2] to the
action – here the lighting in the living
room.
4.
Specify which status the functions
(lamps) have when triggered [3], e.g.:
Hue lamp on
Hue light colour: warm white
Illumination at 45 percent
3
5.
Create further actions in the same
way for the
lighting and blinds control
with the relevant functions from
Areas &
Functions.
Note: all functions that are added to
an action are run at the same time.
SMART VISU SERVER + PRESENCE SIMULATION 9
