Mocka Maya Entertainment Unit Assembly Instructions Manual page 8

Maya Entertainment Unit
Jolt Wardrobe
Assembly Instructions
13
Drawers x3
12
B
B
11
Attach panels [12] and [13] to panel [11] with 4x locking nuts (B).
Tighten with a screwdriver.
mocka.co.nz | mocka.com.au mocka.co.nz | mocka.com.au | PO BOX 6171, Maroochydore, QLD, 4558
13
B
B
B
14
Drawers x3
12
11
Slide panel [14] along the grooves between the side panels [12] and
[13] to form the base of the drawer.
14
13
8
