Maya Entertainment Unit
Assembly Instructions
7
C
B
Attach 2x panels [7] to panel [6] with 4x dowels (C) and secure with
4x locking nuts (B) and tighten with a screwdriver.
mocka.co.nz | mocka.com.au
| PO BOX 6171, Maroochydore, QLD, 4558
B
6
C
B
7
B
7
B
8
Slide panel [9] between the grooves of panels [2] ,[3] and [6] to form
the back of the unit, as shown.
9
