Mocka Maya Entertainment Unit Assembly Instructions Manual page 4

Maya Entertainment Unit
Assembly Instructions
5
5
5
C
Attach 2x panels [5] to panel [6] with 4x dowels (C) and secure with
4x long screws (R) and tighten with a screwdriver.
mocka.co.nz | mocka.com.au | PO BOX 6171, Maroochydore, QLD, 4558
C
R
6
R
R
R
6
1
B
5
N
B
2
8
Slide panel [8] between the grooves of panels [2] ,[3] and [6] to form
the back of the unit, as shown. Attach panel [1] to the rest of
the unit and secure with 8x locking nuts (B) and tighten with a
screwdriver. Seal the holes with 8 x covers (N).
N
3
B
N
5
B
N
B
4
