Maya Bedside Table
Assembly Instructions
Thank you for your purchase.
Please follow the instructions below for correct assembly.
A
B
C
bolt
locking
dowel
x 12
nut x12
x8
F
H
G
small
bracket
screw
x4
screw x9
x16
Hardware Supplied
Phillips & Flathead screwdriver and hammer required
For quicker assembly, we recommend the
use of a power drill on a low-speed setting.
mocka.co.nz | mocka.com.au
V
D
E
screw
stopper
Safety
x1
Strap
x4
x1
I
X
screw
wall
x1
anchor
x1
Wall Strap
*We recommend using a Flathead screwdriver to tighten all locking nuts 100% before first use.
Please clear any loose wood from the locking nut holes before inserting the nut to ensure it locks 100%.
WARNING:
W
tip over in certain circumstances, i.e. if a child attempts to climb up on the
furniture or in the event of an earthquake. Accordingly, we recommend that
all furniture is anchored to a wall. We supply a free safety wall anchor with
all furniture sold and we recommend these are used to prevent your product
tipping. The fixing device provided should fit most wall types, but please
note that different wall materials may require different fixing devices from
those supplied.
Wall
Screw
x1
Y
r/washer
screw
x1
Z
washer
x2
Any furniture that is not anchored to a wall has the potential to
1
