Maya Entertainment Unit
Assembly Instructions
1
1
A
C
A
C
A
C
A
C
6
Insert 8x bolts (A) and 8x dowels (C) into panel [1]. Insert 4x bolts
(A) into panel [6]. Tighten with a screwdriver.
mocka.co.nz | mocka.com.au | PO BOX 6171, Maroochydore, QLD, 4558
A
C
A
C
A
C
A
C
A
A
A
A
2
F
A
A
C
2
C
A
3
A
C
C
F
F
F
J
Attach 1x CL runner track (I) to panel [2] and secure with 3x small
screws (F). Attach 1x CR runner track (J) to panel [3] and secure
with 3x small screws (F). Insert 4x bolts (A) and 4x dowels (C) into
panels [2] and [3]. Tighten with a screwdriver.
F
F
F
I
I
F
CR
J
CL
2
