Mocka Make-Up Table
Assembly Instructions
Thank you for your purchase.
Please follow the instructions below for correct assembly.
A
B
bolt
locking
dowel
x20
x34
nut x20
E
F
G
slide
slide
screw
rail x2
rail x2
x10
Hardware Supplied
Phillips & Flathead screwdrivers required
For quicker assembly, we recommend the
use of a power drill on a low-speed setting.
mocka.co.nz | mocka.com.au
C
D
W
screw
x6
safety
strap x1
H
X
covers
wall
x10
anchor
x1
Wall Strap
*We recommend using a Flathead screwdriver to tighten all locking nuts 100% before first use.
Please clear any loose wood from the locking nut holes before inserting the nut to ensure it locks 100%.
WARNING:
over in certain circumstances, i.e. if a child attempts to climb up on the furniture
or in the event of an earthquake. Accordingly, we recommend that all furniture
is anchored to a wall. We supply a free safety wall anchor with all furniture sold
and we recommend these are used to prevent your product tipping. The fixing
device provided should fit most wall types, but please note that different wall
materials may require different fixing devices from those supplied.
wall
screw x1
Y
r/washer
screw
x1
Z
washer
x1
Any furniture that is not anchored to a wall has the potential to tip
1
Advertisement
Related Manuals for Mocka Make-Up Table
Summary of Contents for Mocka Make-Up Table
- Page 1 Mocka Make-Up Table Assembly Instructions Thank you for your purchase. Please follow the instructions below for correct assembly. WARNING: Any furniture that is not anchored to a wall has the potential to tip over in certain circumstances, i.e. if a child attempts to climb up on the furniture or in the event of an earthquake.
- Page 2 Mocka Make-Up Table Assembly Instructions Attach panel [12] to panel [13] using 2x dowels (C). Repeat this step to Attach the other panels [12] to panel [13] with 4x dowels (C) as shown. assemble another section. mocka.co.nz | mocka.com.au...
- Page 3 Mocka Make-Up Table Assembly Instructions Attach panels [12] to panel [11] using 8x dowels (C). Attach 1x slide rail (F) to panel [9] using 2x screws (E). Attach 1x slide rail (F) to panel [10] using 2x screws (E). Tighten with a screwdriver.
- Page 4 Mocka Make-Up Table Assembly Instructions Attach panel [9] to panel [13] using 2x dowels (C) and secure with 2x Slide panel [7] along the grooves between panels [9] and [10]. screws (D). Attach panel [10] to panel [13] using 2x dowels (C) and secure with 2x screws (D).
- Page 5 Mocka Make-Up Table Jolt Wardrobe Assembly Instructions ASSEMBLY INSTRUCTIONS Attach panels [8] to panel [11] as shown using 2x screws (D). Tighten Attach panel [6] as shown using 8x dowels (C), 6x bolts (A) and secure with a screwdriver. with 6x locking nuts (B) as shown. Tighten with a screwdriver. Use 4x stickers (H) to cover the holes where locking nuts (B) are used as shown.
- Page 6 Mocka Make-Up Table Assembly Instructions Attach 1x slide rail (G) to panel [2] using 3x screws (E). Attach 1x slide Attach panel [4] to panel [2] using 2x bolts (A) and secure with 2x locking rail (G) to panel [3] using 3x screws (E). Tighten with a screwdriver.
- Page 7 Mocka Make-Up Table Assembly Instructions Wall Strap Insert 8x bolts (A) into panel [1] and attach 1x safety strap (W) using 1x Attach panel [4] to panel [3] using 2x bolts (A) and secure with 2x screw (Y). Tighten with a screwdriver.
- Page 8 Mocka Make-Up Table Assembly Instructions Insert the drawers into the unit ensuring it smoothly and easily slides Attach panel [1] to panels [2] and [3] using 4x dowels (C) and secure with along the rails. 8x locking nuts (B). Tighten with a screwdriver. Use 2x stickers (H) to cover the rear holes where locking nuts (B) are used.
- Page 9 Mocka Make-Up Table Assembly Instructions Wall Strap Ensure the unit is balaced and steady before use. You’re done, enjoy! Once assembled lift furniture into place, do not drag. Use a drill to create a small hole lining up with the top of the safety strap (W). Fasten to wall using 1x wall plug (X), 1x washer (Z) and 1x wall screw (not supplied).
