Specifications
Uplink Frequency Range (MHz):
Downlink Frequency Range (MHz):
Donor/Server Port Impedance:
Maximum Gain:
Noise Figure:
VSWR:
Supported Standards:
AC Input:
Maximum Output Power:
Cable:
RF Connectors:
Power Consumption:
Weight:
Dimensions:
Certifications: (Flare 3.0)
Note: The term "IC" before the radio certification number only signifies that Industry Canada technical specifications were met.
Kitting Information
Component
Product
number
Outdoor Antenna*
SC-289W
SC-231W
Outdoor Cable*
SC-RG6-50
Indoor Antenna
SC-322W
*Note: The Flare 3.0 booster is suitable for use with all equivalent and lower gain antennas, as well as, equivalent or greater lengths of cable.
12
SPECIFICATIONS
698–716 / 776–787 (Bands: 12, 13)
728–746 / 746–757 (Bands: 12, 13)
75 ohm / 50 ohm
72 dB
7 dB
≤2.0
CDMA, WCDMA, GSM, EDGE, HSPA+, EVDO 4G and all cellular standards
Input: AC 110 – 240 V, 60 Hz ; Output: DC 5V / 3A
1 Watt EIRP
RG6 (50 ft.)
Donor port: F Female, Server port: Integral
<12W
1. 8125 lb.
5.125 × 7.25 × 5.625 inches
FCC ID: RSNFLARE-3 ; IC : 7784A-FLARE3
Gain/Loss
707 MHz
731 MHz
3 dBi
3 dBi
8 dBi
8 dBi
3.32 dB
3.32 dB
2.5 dBi
2.5 dBi
https://www.signalbooster.com | 855.846.2654 | order@signalbooster.com
Note
50 Feet or longer
