ACX2200 Universal Access Routers Quick Start
Configure System Attributes
Commit the Configuration
18
Configure the name of the router. If the name includes spaces, enclose the name in
1.
quotation marks (" ").
[edit]
root@# set system host-name host-name
Configure the router's domain name.
2.
[edit]
root@# set system domain-name domain-name
Configure the IP address and prefix length for the router's Ethernet interface.
3.
[edit]
root@# set interfaces fxp0 unit 0 family inet address address/prefix-length
Configure the IP address of a backup router, which is used only while the routing
4.
protocol is not running.
[edit]
root@# set system backup-router address
Configure the IP address of a DNS server.
5.
[edit]
root@# set system name-server address
(Optional) Configure the static routes to remote subnets with access to the
6.
management port. Access to the management port is limited to the local subnet. To
access the management port from a remote subnet, you need to add a static route
to that subnet within the routing table. For more information about static routes, see
the Junos OS Administration Library for Routing Devices.
[edit]
root@# set routing-options static route remote-subnet next-hop destination-IP retain
no-readvertise
Configure the telnet service at the
7.
[edit]
root@# set system services telnet
(Optional) Display the configuration to verify that it is correct.
1.
[edit]
root@# show
system {
host-name host-name;
domain-name domain-name;
backup-router address;
root-authentication {
authentication-method (password | public-key);
}
name-server {
address;
hierarchy level.
[edit system services]
Copyright © 2016, Juniper Networks, Inc.
