2.4.1
Option 1: Attach the mounting plate to TX3-NANO-BB
1.
2.
TX3 Nano Installation Manual
12
Copyright 2018
To prevent water from flowing into the TX3-NANO-BB mounting box,
apply outdoor-rated weatherproof silicone around the 4 holes on the back
of the mounting box (the side against the wall) as shown in Figure 5.
TX3-NANO-BB (back view)
Figure 5. Apply silicone around the holes on the back of TX3-
NANO-BB
Mount TX3-NANO-BB to the wall with 4 fasteners appropriate for the
type of wall.
Apply outdoor-rated
weatherproof silicone
around the 4 holes
on the back of
TX3-NANO-BB
Mounting
