Appendix C: Warming system response by temperature

Fluid Temp Heater Temperature LED on Warmer
30 °C Active Blue Flashing
31 °C Active Blue Flashing
32 °C Active Blue Flashing
33 °C Active Blue
34 °C Active Blue
35 °C Active Green
36 °C Active Green
37 °C Active Green
38 °C Active Green
39 °C Active Green
40 °C Active Green
41 °C Off Green
42 °C Off Green
43 °C Off Yellow
44 °C Off Yellow
45 °C Off Red Flashing High Priority Alarm after 20 seconds
46 °C Off Red Flashing High Priority Alarm after 16 seconds
47 °C Off Red Flashing High Priority Alarm after 12 seconds
48 °C Off Red Flashing High Priority Alarm after 8 seconds
49 °C Off Red Flashing High Priority Alarm after 4 seconds
50 °C Off Red Flashing High Priority Alarm (immediately)
4400-0024-EN Rev A
Display on Controller
30 °C Blue Flashing
31 °C Blue Flashing
32 °C Blue Flashing
33 °C Blue
34 °C Blue
35 °C Green
36 °C Green
37 °C Green
38 °C Green
39 °C Green
40 °C Green
41 °C Green
42 °C Green
43 °C Yellow
44 °C Yellow
45 °C after 20 seconds Red Flashing "Over Temp" message
46 °C after 16 seconds Red Flashing "Over Temp" message
47 °C after 12 seconds Red Flashing "Over Temp" message
48 °C after 8 seconds Red Flashing "Over Temp" message
49 °C after 4 seconds Red Flashing "Over Temp" message
Red Flashing Over Temp message (immediately)
- 26 of 40 -
Audible Alarm
No
No
No
No
No
No
No
No
No
No
No
No
No
No
No
After 20 seconds
After 16 seconds
After 12 seconds
After 8 seconds
After 4 seconds
Immediately
