49.808854
49.808859
49.808863
49.808867
49.808871
49.808875
49.808880
49.808884
j. Press SW2 on the BLE Pioneer kit to set Connectable Advertisement mode for the Indoor Positioning Service. The
green LED on the BLE Pioneer kit indicates this mode.
k. On the CySmart Host Emulation Tool, click Stop Scan and click Start Scan. Your device name (IPS) should appear in
the Discovered devices list, as
between the CySmart Host Emulation Tool and your device.
l. Click Pair. Click Yes to a pairing request received from the peer device.
m. Enter the passkey, displayed in the CySmart window, in the terminal window to confirm the Numeric
comparison pairing procedure.
n. Click Discover All Attributes, then click Read All Characteristics in the CySmart application. Observe the
received characteristic values.
o. Change the Floor Number characteristic value to 22 (for example) and click Write Value, then click Read
Value. Observe the changes in CySmart and HyperTerminal. See
q. Change the Indoor Positioning Configuration characteristic value to 51 and click Write Value, then click Read Value.
Observe the result in CySmart and HyperTerminal
Number in the advertisement packet. For details, see
www.cypress.com
Latitude
0x46D6D9B9
0x46D6DA1D
0x46D6DA81
0x46D6DAE5
0x46D6DB49
0x46D6DBAD
0x46D6DC11
0x46D6DC75
Figure 6 shows. Select the device and click Connect to establish a BLE connection
Figure 6. CySmart Device Discovery and Connection
Figure 7. CySmart Attribute Discovery and Characteristics Read
Document No. 002-17647 Rev.**
BLE Indoor Positioning with PSoC 6 MCU with BLE Connectivity
Longitude
24.041609
24.041617
24.041626
24.041634
24.041642
24.041651
24.041659
24.041668
Figure
(Figure 8). Value 51 sets only the Latitude, Longitude, and Floor
Indoor Positioning Service
0x1118A42F
0x1118A493
0x1118A4F7
0x1118A55B
0x1118A5BF
0x1118A623
0x1118A687
0x1118A6EB
8.
Specification.
