- Page 1 HOSE REEL MODEL No: CAR8P & CAR15P INSTRUCTIONS FOR USE 0405...
- Page 2 In doing so, the Reel will provide you with many years of satisfactory service. GUARANTEE his CLARKE product is guaranteed against faulty manufacture for a period of 12 months from the date of purchase. Please keep your receipt as proof of purchase.
- Page 3 SAFETY PRECAUTIONS • Never exceed the rated operating pressure for this device. • Eye protection should be used when assembling and using the hose reel. • Take ALL precautions with respect to the use of compressed air. Remember..compressed air can kill. •...
- Page 4 The swivel seals will need replacing due to normal wear and tear, from time to time. This is carried out as follows: A. Model CAR8P 1. Remove the 4 side cover securing screws ‘A’ and pull off the cover to reveal the swivel hub -’C’.
- Page 5 Reassemble in reverse order. PARTS AND SERVICE CONTACTS For Spare Parts and Service, please contact your nearest dealer, or CLARKE International, on one of the following numbers. PARTS & SERVICE TEL: 020 8988 7400 PARTS & SERVICE FAX: 020 8558 3622 e-mail as follows: PARTS: Parts@clarkeinternational.com...
- Page 6 PARTS - CAR8P No. Description Part No. No. Description Part No. Screw CAR8P01 15 Ratchet Pawl CAR8P15 Side Cover CAR8P02 16 Ratchet Shaft CAR8P16 Swivel Connector CAR8P03 17 Spring CAR8P17 O-Ring CAR8P04 18 Mounting Bracket CAR8P18 19 Outer Casing CAR8P19...
- Page 7 PARTS - CAR15P No.Description Part No. No.Description Part No. 1 Outer Casing - Adj. side CAR15P01 20 Bushing CAR15P20 2 Outer Casing - Inlet side CAR15P02 21 Swivel Connector CAR15P21 3 Drum - Air Inlet side CAR15P03 22 Fitting CAR15P22 4 Drum - Adjuster side CAR15P04 23 O-Ring...
