Savant® REM-1000 Pro System Remote and Base
Quick Reference Guide
Box Contents
(1) Savant Pro Remote (SUR-1000)
(1) Savant Pro Remote Base (SRB-1000)
(1) USB Power Supply with international blades (025-0162-xx)
(1) 1.5 m USB A to micro USB B cable (064-0409-xx)
(1) Quick Reference Guide (this document)
Specifications
Environments
Temperature
32° to 104° F (0° to 40°C)
Humidity
10% to 90% (non-condensing)
Dimensions
Remote
Base
(SUR-1000)
(SRB-1000)
Height
7.25 in (18.42 cm)
1.17 in (2.97 cm)
Width
2.0 in (5.08 cm)
4.17 in (10.59 cm)
Depth
1.06 in (2.7 cm)
3.10 in (7.87 cm)
Weight
0.35 lb (0.16 kg)
0.35 lb (0.16 kg)
Power
Power Supply
100/240V AC (60/50 Hz) to 5V DC 2A
Base Input
5V DC 2A
Remote Battery
Rechargeable
Touch Screen (LCD)
High Resolution Multi Color Touchscreen Display
2.57 in (6.53 cm) x 1.46 in (3.7 cm)
LCD Dimensions
Diagonal 2.95 in (7.49 cm)
Standards
Wireless
Wi-Fi® (802.11 b/g/n 2.4 GHz)
Bluetooth
Bluetooth v4.0
Security
WPA1™, WPA2™, WPA1™ + WPA2™, WEP
Regulatory
Safety and
FCC Part 15 | CE Mark |
Emissions
C-Tick | UL
Pro Remote Base
Contains FCC ID:
TLZ-CU277
Contains IC:
6100A-CU277
Pro Remote
FCC ID:
ASU-CRU0100
IC:
10052A-CRU0100
RoHS
Compliant
Minimum Supported Release
Savant OS
da Vinci 8.0
Additional Information
• The Pro Remote and Base need to be within 30 feet (9.14m) of
each other to communicate.
• Up to two Pro Remotes per user zone is supported.
• Automatic software updates to the Remote will initiate if it is
left cradled overnight and no A/V services are active.
• Software updates can be initiated manually from the About
page on the remote (only if update is available).
• The Pro Remote Base will receive firmware updates when an
updated version of firmware is available in the da Vinci
software running on the host.
REM-1000-00 | 009-1378-00 | 160326
Copyright © 2016 Savant Systems, LLC
Remote and Base
Shipping
3.7 in (9.40 cm)
4.9 in (12.45 cm)
8.8 in (22.35 cm)
1.7 lb (0.77 kg)
Power Button
Microphone
Touchscreen
Display
Volume
Channel
Scroll / Select
Voice
Command
Remote Base
Press/Release
• With the remote powered on, the power button
can toggle the last used A/V service on or off.
• Powers the Remote On. Remote will take about
5-7 seconds before Savant Logo appears.
Press/Hold (5 sec.) – Powers remote Off.
The microphone for Voice Commands is positioned
behind the small hole on top of remote.
Multi-colored LCD display with multiple pages for
viewing and control of available services.
• Motion activated.
• One touch and swipe operation
• Controls for services
Increase or Decrease volume of the service selected on
the touchscreen display (active service).
Channel Up or Channel Down the service selected on
the touchscreen display (active service).
Standard up, down, left, and right arrows for on-screen
control. Press and hold the up/down arrows to page up
or page down the on-screen menus. Press the Select
button to select the highlighted item.
Activate services, scenes, environmental controls, and
various other functions using voice commands. Press
and hold the Voice Command button, wait for the on-
screen prompt, and speak the commands clearly.
TIP!
Speak the phrase Voice Commands into the
Remote to open a list of supported commands.
Charging
Charges the battery when the
Station
Remote is set into the Remote Base.
Wi-Fi Base
Communicates with the Savant Host
Station
over the local Wi-Fi network.
Bluetooth Base
Communicates with the Pro Remote
Station
using Bluetooth v4.0.
45 Perseverance Way, Hyannis, MA 02601
Savant.com
For Product Info
| 508.683.2500
