Installing a Filter Cube
To install a filter cube:
1. In the CellReporterXpress software, on the Home page, click
2. In the Available Acquisition Devices list, click
details for the device where you want to install a filter cube.
3. Click the Filters tab.
4. In the tile for the filter cube slot where you want to install, click
Exchange.
5. Click the Choose Filter drop-down list box, and select the filter cube you want to install.
6. Click Open Maintenance Door.
7. If needed, slightly rotate the filter cube turret by hand to get direct access to the filter
cube slot.
8. Install the filter cube in the slot by gently pushing it into the slot until it "snaps" into
place.
9. Do both of the following:
a. Manually close the maintenance door.
b. In the CellReporterXpress software, click Close Maintenance Door.
10. Click Apply.
5063666 F
Note: Do not install a filter cube in slot 6 of the turret. Slot 6 must be empty (in
both the instrument and the software).
CAUTION! Retain the filter cube packaging for future storage needs. When not
installed in the instrument, a filter cube should always be stored in its original
packaging.
Chapter 4: Finishing Setup of the ImageXpress Pico System
Show Device Options to expand the
Devices.
