Bartec BCS36 8ex Series Supplementary Description

Hide thumbs
Table of Contents

Advertisement

Quick Links

BCS36x8
Series
Connection example
ex
Type 17-A1S4-*HP* and B7-A2S4-****
Supplementary description – Translation of the original
Connection examples for USB, RS232 and HID
BCS36x8
Series
ex
Type 17-A1S4-*HP*
ATEX / IECEx Zone 1/21
NEC / CEC Class I, II, III Division 1
Type B7-A2S4-*HP* and B7-A2S4-*ER*
ATEX / IECEx Zone 2/22
NEC / CEC Class I, II, III Division 2
Date: 05
May 2020
th
Disclaimer: We reserve the right to make technical changes. Changes, errors
and misprints shall not justify any claim for damages.
GmbH
Max-Eyth-Straße 16
Phone: +49 (0) 7931 597-0
97980 Bad Mergentheim,
Fax: +49 (0) 7931 597-119
GERMANY
Support:
em-support@bartec.com
Download:
http://automation.bartec.de
Internet:
www.bartec.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the BCS36 8ex Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Bartec BCS36 8ex Series

Summary of Contents for Bartec BCS36 8ex Series

  • Page 1 Disclaimer: We reserve the right to make technical changes. Changes, errors and misprints shall not justify any claim for damages. GmbH Max-Eyth-Straße 16 Phone: +49 (0) 7931 597-0 Support: em-support@bartec.com 97980 Bad Mergentheim, Fax: +49 (0) 7931 597-119 Download: http://automation.bartec.de GERMANY Internet: www.bartec.com...

  • Page 2: Table Of Contents

    BCS36x8 Series Connection example Type 17-A1S4-*HP* and B7-A2S4-**** Table of contents Table of contents............................2  1.  About this documentation....................... 4  1.1  Technical changes ........................4  1.2  Languages ..........................4  1.3  Other relevant documents ...................... 5  2.  Note ..............................6  3.  Programming Tools .........................
  • Page 3 BCS36x8 Series Connection example Type 17-A1S4-*HP* and B7-A2S4-**** 9.1.1  Components required ..................... 39  9.1.2  Connection ......................40  9.1.3  Setting/programming ....................41  9.1.4  Testing communication/data transmission .............. 43  10.  Bluetooth BCS3678 hand-held scanner ..................44  10.1  Connection as HID device ....................44  10.1.1 ...

  • Page 4: About This Documentation

    The current versions of data sheets, manuals, certificates and EC declarations of conformity as well as information about new accessories can be downloaded from www.bartec.de under “Products & solutions” in the “Automation technology” product area, or can be requested directly from BARTEC GmbH.

  • Page 5: Other Relevant Documents

    BARTEC (global): www.bartec.de BARTEC (ACS): http://automation.bartec.de ‒ ZEBRA (ZEB): www.zebra.com ‒ Where information overlaps with that in Zebra manuals, the instructions in the BARTEC User Manual apply. The BARTEC User Manual takes priority. Document Explanation Download page BARTEC Quick Start Guide...

  • Page 6: Note

    1. Programming via Barcodes. For programming using barcodes, the original Zebras manuals can be used. With the help of the programmable codes, extensive settings can be made on the scanner. available on: BARTEC download page: http://automation.bartec.de/scanner.htm Zebra support download page: https://www.zebra.com/us/en/support-downloads.html - Barcode Scanners - Ultra Rugged Scanners --- DS3608-HP/DS3678-HP;...
  • Page 7 Further notes on programming can be found in the:  BARTEC user manual.  Original Zebra documentation. The explosion-proof BARTEC hand scanners are functionally based on the following Zebra hand scanners: - BCS3608ex-IS is based on Zebra DS3608-HP - BCS3678ex-IS is based on Zebra DS3678-HP...

  • Page 8: Wired Bcs3608 Ex Hand-Held Scanner

    1 x RS232 connection cable to the host PC. Maximum cable length supported: 15 m Number of cores and recommended cable cross section: see BARTEC User Manual. (http://automation.bartec.de/scanner.htm) – The default setting for the hand-held scanner is as an HID device. The serial interface still needs to be activated with the help of a programming barcode.

  • Page 9: Connection

    BCS36x8 Series Connection example Type 17-A1S4-*HP* and B7-A2S4-**** 4.1.2 Connection Diagram Pos. Description Power supply (100 to 240 V ±10% / 50/60 Hz or 24 V ±10% 0.4A) Note: NEC/CEC version only with 24V Host PC RS232 data cable from host PC to universal supply module (max. 15m) Universal supply module for hand-held scanners BCS 3608 connection cable...
  • Page 10 BCS36x8 Series Connection example Type 17-A1S4-*HP* and B7-A2S4-**** Universal supply module - terminal assignment Terminal Mains connection / RS232 interface L (230V) L = 100 V to 240 V ±10% / 50/60 Hz N (230V) N = Neutral conductor + (24V) 24 V + ±10% / 0,4A - (24V)
  • Page 11 On connecting the USM, the drivers are automatically detected by the Windows operating system and installed if necessary. If not detected automatically, the driver can be downloaded from the BARTEC download page or directly from the FTDI website ( ) and installed manually.

  • Page 12: Setting/Programming

    The functions of the BCS3608 and BCS3678 are based on the Zebra DS3608-HP/DS3608-ER and DS3678-HP/DS3678-ER. The Guide is available to download from Zebra or from BARTEC: Zebra support download page: https://www.zebra.com/us/en/support-downloads.html Barcode Scanners Ultra Rugged Scanners – DS3608-HP/DS3678-HP and DS3608-ER/DS3678-ER BARTEC download page: http://automation.bartec.de/indexE.htm...

  • Page 13: Testing Communication/Data Transmission

    BCS36x8 Series Connection example Type 17-A1S4-*HP* and B7-A2S4-**** Further customized settings can be performed with the help of the Zebra Product Reference Guide or the Zebra 123Scan utility. Programming/setting via the Zebra 123 Scan Utility is not supported via the USM. A programming cable is required.
  • Page 14 BCS36x8 Series Connection example Type 17-A1S4-*HP* and B7-A2S4-**** Data transmission is OK if the barcode data is displayed in the “Received Data” window. If not, check connection and programming. Subject to technical changes. Page 14 of 78 05/2020...

  • Page 15: Wired Bcs3608 Ex Hand-Held Scanner

    1 x USB connection cable to the host PC Maximum cable length supported: 5 m Number of cores and recommended cable cross section: see BARTEC User Manual. (http://automation.bartec.de/scanner.htm) – USB only functions as SPP (Serial Port Profile), HID is not supported.

  • Page 16: Connection

    BCS36x8 Series Connection example Type 17-A1S4-*HP* and B7-A2S4-**** 5.1.2 Connection Diagram Pos. Description Power supply (100 to 240 V ±10% / 50/60 Hz or 24 V ±10% 0.4A) Note: NEC/CEC version only with 24V Host PC USB data cable from host PC to universal supply module (max. 5m) Universal supply module for hand-held scanners BCS 3608 connection cable...
  • Page 17 BCS36x8 Series Connection example Type 17-A1S4-*HP* and B7-A2S4-**** Universal supply module - terminal assignment Terminal Mains connection / RS232 interface L (230V) L = 100 V to 240 V ±10% / 50/60 Hz N (230V) N = Neutral conductor + (24V) 24 V + ±10% / 0.4A - (24V)
  • Page 18 On connecting the USM, the drivers are automatically detected by the Windows operating system and installed if necessary. If not detected automatically, the driver can be downloaded from the BARTEC download page or directly from the FTDI website (https://www.ftdichip.com/) and installed manually.

  • Page 19: Setting/Programming

    The programming barcodes have been taken from the original Zebra Product Reference Guide (PRG). The functions of the BCS3608 and BCS3678 are based on the Zebra DS3608-HP and DS3678-HP. The Guide is available to download from Zebra or from BARTEC: Zebra support download page: https://www.zebra.com/us/en/support-downloads.html Barcode Scanners Ultra Rugged Scanners –...

  • Page 20: Testing Communication/Data Transmission

    BCS36x8 Series Connection example Type 17-A1S4-*HP* and B7-A2S4-**** 5.1.4 Testing communication/data transmission The communication/data transmission on the host PC can be tested with the help of a terminal program or a software keyboard wedge. A software wedge or other application must be installed on the host PC for data transmission when using a universal supply module.

  • Page 21: Bluetooth Bcs3678 Ex Hand-Held Scanner

    1 x RS232 connection cable to the host PC Maximum cable length supported: 15m Number of cores and recommended cable cross section: see BARTEC User Manual. (http://automation.bartec.de/scanner.htm ) – The default setting for the hand-held scanner is as HID device. The serial interface still needs to be activated with the help of a programming barcode.

  • Page 22: Connection

    BCS36x8 Series Connection example Type 17-A1S4-*HP* and B7-A2S4-**** 6.1.2 Connection Diagram Pos. Description Power supply (100 to 240 V ±10% / 50/60 Hz or 24 V ±10% 0.4A) Note: NEC/CEC version only with 24V Host PC RS232 data cable from host PC to the universal supply module (max. 15m) Universal supply module for hand-held scanners BCS 3678 hand-held scanner...
  • Page 23 BCS36x8 Series Connection example Type 17-A1S4-*HP* and B7-A2S4-**** Universal supply module - terminal assignment Terminal Mains connection / RS232 interface L (230V) L = 100 V to 240 V ±10% / 50/60 Hz N (230V) N = Neutral conductor + (24V) 24 V + ±10% / 0,4A - (24V)
  • Page 24 On connecting the USM, the drivers are automatically detected by the Windows operating system and installed if necessary. If not detected automatically, the driver can be downloaded from the BARTEC download page or directly from the FTDI website (https://www.ftdichip.com/) and installed manually.

  • Page 25: Setting/Programming

    The functions of the BCS3608 and BCS3678 are based on the Zebra DS3608-HP/ER and DS3678-HP/ER. The Guide is available to download from Zebra or from BARTEC: Zebra support download page: https://www.zebra.com/us/en/support-downloads.html Barcode Scanners Ultra Rugged Scanners – DS3608-HP/DS3678-HP and DS3608-ER/DS3678-ER BARTEC download page: http://automation.bartec.de/indexE.htm...
  • Page 26 BCS36x8 Series Connection example Type 17-A1S4-*HP* and B7-A2S4-**** Scan in the pairing barcode on the universal supply module. The barcode can be found on the cover. The barcode for pairing can be created at any time using the Zebra 123Scan utility. Use the MAC address of the Bluetooth module in the universal supply module for this.

  • Page 27: Testing Communication/Data Transmission

    BCS36x8 Series Connection example Type 17-A1S4-*HP* and B7-A2S4-**** 6.1.4 Testing communication/data transmission The communication/data transmission on the host PC can be tested with the help of a terminal program or a software keyboard wedge. A software wedge or other application must be installed on the host PC for data transmission when using a universal supply module.

  • Page 28: Bluetooth Bcs3678 Ex Hand-Held Scanner

    1 x USB connection cable to the host PC. Maximum cable length supported: 5 m Number of cores and recommended cable cross section: see BARTEC User Manual. (http://automation.bartec.de/scanner.htm) – USB only functions as SPP (Serial Port Profile), HID is not supported.

  • Page 29: Connection

    BCS36x8 Series Connection example Type 17-A1S4-*HP* and B7-A2S4-**** 7.1.2 Connection Diagram Pos. Description Power supply (100 to 240 V ±10% / 50/60 Hz or 24 V ±10% 0.4A) Note: NEC/CEC version only with 24V Host PC RS232 data cable from host PC to universal supply module (max. 15m) Universal supply module for hand-held scanners BCS 3678 hand-held scanner...
  • Page 30 BCS36x8 Series Connection example Type 17-A1S4-*HP* and B7-A2S4-**** Universal supply module - terminal assignment Terminal Mains connection / RS232 interface L (230V) L = 100 V to 240 V ±10% / 50/60 Hz N (230V) N = Neutral conductor + (24V) 24 V + ±10% / 0.4A - (24V)
  • Page 31 On connecting the USM, the drivers are automatically detected by the Windows operating system and installed if necessary. If not detected automatically, the driver can be downloaded from the BARTEC download page or directly from the FTDI website (https://www.ftdichip.com/) and installed manually.

  • Page 32: Setting/Programming

    The functions of the BCS3608 and BCS3678 are based on the Zebra DS3608-HP/ER and DS3678-HP/ER. The Guide is available to download from Zebra or from BARTEC: Zebra support download page: https://www.zebra.com/us/en/support-downloads.html Barcode Scanners Ultra Rugged Scanners – DS3608-HP/DS3678-HP and DS3608-ER/DS3678-ER BARTEC download page: http://automation.bartec.de/indexE.htm...
  • Page 33 BCS36x8 Series Connection example Type 17-A1S4-*HP* and B7-A2S4-**** Scan in the pairing barcode on the universal supply module. The barcode can be found on the cover. The barcode for pairing can be created at any time using the Zebra 123Scan utility. Use the MAC address of the Bluetooth module in the universal supply module for this.

  • Page 34: Testing Communication/Data Transmission

    BCS36x8 Series Connection example Type 17-A1S4-*HP* and B7-A2S4-**** 7.1.4 Testing communication/data transmission The communication/data transmission on the host PC can be tested with the help of a terminal program or a software keyboard wedge. A software wedge or other application must be installed on the host PC for data transmission when using a universal supply module.

  • Page 35: Bluetooth Bcs3678 Ex Hand-Held Scanner

    BCS36x8 Series Connection example Type 17-A1S4-*HP* and B7-A2S4-**** Bluetooth BCS3678 hand-held scanner Connection via cradle as HID device to host PC 8.1.1 Components required Functional system BCS3678 BCS3678 ATEX / IECEx Zone 1/21 ATEX / IECEx Zone 2/22 NEC / CEC Class I, II, III Division 1 NEC / CEC Class I, II, III Division 2 Bluetooth BCS3678 hand-held scanner...

  • Page 36: Connection

    BCS36x8 Series Connection example Type 17-A1S4-*HP* and B7-A2S4-**** 8.1.2 Connection Diagram Pos. Description Host PC Power supply unit with DC connection cable (input: 100 to 240 V Cradle for hand-held scanner USB connection cable BCS 3678 hand-held scanner Cradle for hand-held scanner Front view with barcode for pairing Rear view with type label including MAC address Cradle –...

  • Page 37: Setting/Programming

    The functions of the BCS3608 and BCS3678 are based on the Zebra DS3608-HP/ER and DS3678-HP/ER. The Guide is available to download from Zebra or from BARTEC: Zebra support download page: https://www.zebra.com/us/en/support-downloads.html Barcode Scanners Ultra Rugged Scanners – DS3608-HP/DS3678-HP and DS3608-ER/DS3678-ER BARTEC download page: http://automation.bartec.de/indexE.htm...

  • Page 38: Testing Communication/Data Transmission

    BCS36x8 Series Connection example Type 17-A1S4-*HP* and B7-A2S4-**** The hand-held scanner is paired to the cradle via Bluetooth. The cradle transmits the data on the output side as USB HID. The cradle is detected by the host PC as USB device. Further customized settings can be performed with the help of the Zebra Product Reference Guide or the Zebra 123Scan utility.

  • Page 39: Bluetooth Bcs3678 Ex Hand-Held Scanner

    BCS36x8 Series Connection example Type 17-A1S4-*HP* and B7-A2S4-**** Bluetooth BCS3678 hand-held scanner Connection via cradle as serial device to host PC 9.1.1 Components required Functional system BCS3678 BCS3678 ATEX / IECEx Zone 1/21 ATEX / IECEx Zone 2/22 NEC / CEC Class I, II, III Division 1 NEC / CEC Class I, II, III Division 2 Bluetooth BCS3678 hand-held scanner...

  • Page 40: Connection

    BCS36x8 Series Connection example Type 17-A1S4-*HP* and B7-A2S4-**** 9.1.2 Connection Diagram Pos. Description Host PC Power supply unit with DC connection cable (input: 100 to 240 V Cradle for hand-held scanner Serial (COM) connection cable BCS 3678 hand-held scanner Cradle for hand-held scanner Front view with barcode for pairing Rear view with type label including MAC address Cradle –...

  • Page 41: Setting/Programming

    The functions of the BCS3608 and BCS3678 are based on the Zebra DS3608-HP/ER and DS3678-HP/ER. The Guide is available to download from Zebra or from BARTEC: Zebra support download page: https://www.zebra.com/us/en/support-downloads.html Barcode Scanners Ultra Rugged Scanners – DS3608-HP/DS3678-HP and DS3608-ER/DS3678-ER BARTEC download page: http://automation.bartec.de/indexE.htm...
  • Page 42 BCS36x8 Series Connection example Type 17-A1S4-*HP* and B7-A2S4-**** The hand-held scanner is set as HID device in factory settings. The serial interface still needs to be activated with the help of a programming barcode. Scan in the “Standard RS-232” barcode to activate the serial RS232 interface.

  • Page 43: Testing Communication/Data Transmission

    BCS36x8 Series Connection example Type 17-A1S4-*HP* and B7-A2S4-**** 9.1.4 Testing communication/data transmission The communication/data transmission on the host PC can be tested with the help of a terminal program or a software keyboard wedge. A software wedge or other application must be installed on the host PC for data transmission when using a serial interface.

  • Page 44: Connection As Hid Device

    BCS36x8 Series Connection example Type 17-A1S4-*HP* and B7-A2S4-**** Bluetooth BCS3678 hand-held scanner 10.1 Connection as HID device 10.1.1 Components required Functional system BCS3678 BCS3678 ATEX / IECEx Zone 1/21 ATEX / IECEx Zone 2/22 NEC / CEC Class I, II, III Division 1 NEC / CEC Class I, II, III Division 2 Bluetooth BCS3678 hand-held scanner...

  • Page 45: Connection

    BCS36x8 Series Connection example Type 17-A1S4-*HP* and B7-A2S4-**** 10.1.2 Connection Diagram Pos. Description Host PC with Bluetooth Mobile device with Bluetooth for non-hazardous areas (e.g. Agile tablet PC or other) Mobile device with Bluetooth for potentially explosive atmospheres (e.g. Agile X or Agile X IS tablet PC, or other) BCS 3678 hand-held scanner...

  • Page 46: Setting/Programming

    The functions of the BCS3608 and BCS3678 are based on the Zebra DS3608-HP/ER and DS3678-HP/ER. The Guide is available to download from Zebra or from BARTEC: Zebra support download page: https://www.zebra.com/us/en/support-downloads.html Barcode Scanners Ultra Rugged Scanners – DS3608-HP/DS3678-HP and DS3608-ER/DS3678-ER BARTEC download page: http://automation.bartec.de/indexE.htm...

  • Page 47: Testing Communication/Data Transmission

    BCS36x8 Series Connection example Type 17-A1S4-*HP* and B7-A2S4-**** The hand-held scanner is directly connected via Bluetooth to the host PC with the Bluetooth module. Data transmitted from the hand-held scanner will be processed by the host PC as keyboard entry. Further customized settings can be performed with the help of the Zebra Product Reference Guide or the Zebra 123Scan utility.

  • Page 48: Supply Module Ex I With Bcs3608

    The Ex relevant data of the power supply module Ex i must match the Ex relevant data of the Ex-HMI or any other Ex-device. The Ex-relevant data of the BARTEC systems can be found in the corresponding Ex certificates, user manuals and data sheets.

  • Page 49: Connection

    Ex-HMI device Note: The Ex-HMI device can be replaced by any other Ex device with serial interface. It is important that the Ex-relevant data must be compatible with the BARTEC components. See BARTEC User Manual Chapter: "Ex-relevant values when connected to power supply module or other systems".
  • Page 50 BCS36x8 Series Connection example Type 17-A1S4-*HP* and B7-A2S4-**** Supply module Ex i - terminal assignment Terminal Mains connection / RS232 interface L = 100 V to 240 V ±10% / 50/60 Hz N = Neutral conductor 24 V + ±10% / 0.4A 24 V –...
  • Page 51 On connecting the supply module, the drivers are automatically detected by the Windows operating system and installed if necessary. If not detected automatically, the driver can be downloaded from the BARTEC download page or directly from the FTDI website (https://www.ftdichip.com/) and installed manually.

  • Page 52: Setting/Programming

    The functions of the BCS3608 and BCS3678 are based on the Zebra DS3608-HP/ER and DS3678-HP/ER. The Guide is available to download from Zebra or from BARTEC: Zebra support download page: https://www.zebra.com/us/en/support-downloads.html Barcode Scanners Ultra Rugged Scanners – DS3608-HP/DS3678-HP and DS3608-ER/DS3678-ER BARTEC download page: http://automation.bartec.de/indexE.htm...

  • Page 53: Testing Communication/Data Transmission

    BCS36x8 Series Connection example Type 17-A1S4-*HP* and B7-A2S4-**** Further customized settings can be performed with the help of the Zebra Product Reference Guide or the Zebra 123Scan utility. Programming/setting via the Zebra 123 Scan Utility is not supported via the supply module Ex i.
  • Page 54 BCS36x8 Series Connection example Type 17-A1S4-*HP* and B7-A2S4-**** Data transmission is OK if the barcode data is displayed in the “Received Data” window. If not, check connection and programming. Subject to technical changes. Page 54 of 78 05/2020...

  • Page 55: Supply Module Ex I With Bcs3608

    The Ex relevant data of the power supply module Ex i must match the Ex-relevant data of the Ex-HMI or any other Ex device. The Ex-relevant data of the BARTEC systems can be found in the corresponding Ex certificates, user manuals and data sheets.

  • Page 56: Connection

    Ex-HMI device Note: The Ex-HMI device can be replaced by any other Ex device with serial interface. It is important that the Ex-relevant data must be compatible with the BARTEC components. See BARTEC User Manual Chapter: "Ex-relevant values when connected to power supply module or other systems".
  • Page 57 On connecting the supply module, the drivers are automatically detected by the Windows operating system and installed if necessary. If not detected automatically, the driver can be downloaded from the BARTEC download page or directly from the FTDI website (https://www.ftdichip.com/) and installed manually.
  • Page 58 BCS36x8 Series Connection example Type 17-A1S4-*HP* and B7-A2S4-**** Wiring of supply module Ex i – USB-SPP interface Ex-HMI/PC/Host with USB Interface Max. cable length is 5 Supply module Ex i - wired USB-SPP = Serial Port Profile USB = virtual serial COM port Wiring: Blue wire ...

  • Page 59: Setting/Programming

    The functions of the BCS3608 and BCS3678 are based on the Zebra DS3608-HP/ER and DS3678-HP/ER. The Guide is available to download from Zebra or from BARTEC: Zebra support download page: https://www.zebra.com/us/en/support-downloads.html Barcode Scanners Ultra Rugged Scanners – DS3608-HP/DS3678-HP and DS3608-ER/DS3678-ER BARTEC download page: http://automation.bartec.de/indexE...

  • Page 60: Testing Communication/Data Transmission

    BCS36x8 Series Connection example Type 17-A1S4-*HP* and B7-A2S4-**** 12.1.4 Testing communication/data transmission The communication/data transmission on the Ex-HMI can be tested with the help of a terminal program or a software keyboard wedge. A software wedge or other application must be installed on the Ex-HMI for data transmission when using a supply module Ex i.

  • Page 61: Supply Module Ex I Bt With Bcs3678

    The Ex relevant data of the power supply module Ex i BT must match the Ex relevant data of the Ex HMI or any other Ex device. The Ex-relevant data of the BARTEC systems can be found in the corresponding Ex certificates, user manuals and data sheets.

  • Page 62: Connection

    Ex-HMI device Note: The Ex-HMI device can be replaced by any other Ex device with serial interface. It is important that the Ex-relevant data must be compatible with the BARTEC components. See BARTEC User Manual Chapter: "Ex-relevant values when connected to power supply module or other systems".
  • Page 63 On connecting the USM, the drivers are automatically detected by the Windows operating system and installed if necessary. If not detected automatically, the driver can be downloaded from the BARTEC download page or directly from the FTDI website (https://www.ftdichip.com/) and installed manually.
  • Page 64 BCS36x8 Series Connection example Type 17-A1S4-*HP* and B7-A2S4-**** Wiring of supply module Ex i BT – RS232 interface Ex-HMI/PC/Host with serial Max. cable length is Supply module Ex i BT - Bluetooth RS232-interface 15 m Wiring: Blue wire  necessary (example connection to AC) Green line necessary ...

  • Page 65: Setting/Programming

    The functions of the BCS3608 and BCS3678 are based on the Zebra DS3608-HP/ER and DS3678-HP/ER. The Guide is available to download from Zebra or from BARTEC: Zebra support download page: https://www.zebra.com/us/en/support-downloads.html Barcode Scanners Ultra Rugged Scanners – DS3608-HP/DS3678-HP and DS3608-ER/DS3678-ER BARTEC download page: http://automation.bartec.de/indexE.htm...
  • Page 66 BCS36x8 Series Connection example Type 17-A1S4-*HP* and B7-A2S4-**** Scan in the pairing barcode on the supply module Ex i BT. The barcode can be found on the cover. The barcode for pairing can be created at any time using the Zebra 123Scan utility. Use the MAC address of the Bluetooth module in the supply module Ex i BT for this.

  • Page 67: Testing Communication/Data Transmission

    BCS36x8 Series Connection example Type 17-A1S4-*HP* and B7-A2S4-**** 13.1.4 Testing communication/data transmission The communication/data transmission on the Ex-HMI device can be tested with the help of a terminal program or a software keyboard wedge. A software wedge or other application must be installed on the Ex-HMI device for data transmission when using a supply module Ex i BT.

  • Page 68: Supply Module Ex I Bt With Bcs3678

    The Ex relevant data of the power supply module Ex i BT must match the Ex-relevant data of the Ex- HMI or any other Ex device. The Ex-relevant data of the BARTEC systems can be found in the corresponding Ex certificates, user manuals and data sheets.

  • Page 69: Connection

    Ex-HMI device Note: The Ex-HMI device can be replaced by any other Ex device with serial interface. It is important that the Ex-relevant data must be compatible with the BARTEC components. See BARTEC User Manual Chapter: "Ex-relevant values when connected to power supply module or other systems".
  • Page 70 On connecting the supply module, the drivers are automatically detected by the Windows operating system and installed if necessary. If not detected automatically, the driver can be downloaded from the BARTEC download page or directly from the FTDI website (https://www.ftdichip.com/) and installed manually.
  • Page 71 BCS36x8 Series Connection example Type 17-A1S4-*HP* and B7-A2S4-**** Wiring of supply module Ex i BT – USB-SPP interface Ex-HMI/PC/Host with USB Interface Max. cable length is 5 Supply module Ex i BT - Bluetooth USB-SPP = Serial Port Profile USB = virtual serial COM port Wiring: Blue wire ...

  • Page 72: Setting/Programming

    The functions of the BCS3608 and BCS3678 are based on the Zebra DS3608-HP/ER and DS3678-HP/ER. The Guide is available to download from Zebra or from BARTEC: Zebra support download page: https://www.zebra.com/us/en/support-downloads.html Barcode Scanners Ultra Rugged Scanners – DS3608-HP/DS3678-HP and DS3608-ER/DS3678-ER BARTEC download page: http://automation.bartec.de/indexE.htm...
  • Page 73 BCS36x8 Series Connection example Type 17-A1S4-*HP* and B7-A2S4-**** Scan in the pairing barcode on the supply module Ex i BT. The barcode can be found on the cover. The barcode for pairing can be created at any time using the Zebra 123Scan utility. Use the MAC address of the Bluetooth module in the supply module Ex i BT for this.

  • Page 74: Testing Communication/Data Transmission

    BCS36x8 Series Connection example Type 17-A1S4-*HP* and B7-A2S4-**** 14.1.4 Testing communication/data transmission The communication/data transmission on the Ex-HMI device can be tested with the help of a terminal program or a software keyboard wedge. A software wedge or other application must be installed on the Ex-HMI device for data transmission when using a supply module Ex i BT.

  • Page 75: Bluetooth Bcs3608 Ex Hand-Held Scanner With Hmi Limiting Cable

    The Ex-relevant data of the hand-held scanner must match the Ex-relevant data of the Ex-HMI or any other Ex-device. The Ex-relevant data of the BARTEC systems can be found in the corresponding Ex certificates, user manuals and data sheets. (www.bartec.com Subject to technical changes.

  • Page 76: Connection

    Functional requirement: USB interface must supply 5V /500 mA on the output side. It is important that the Ex-relevant data must be compatible with the BARTEC components. See BARTEC User Manual Chapter: "Ex-relevant values when connected to power supply module or other systems".

  • Page 77: Setting/Programming

    The functions of the BCS3608 and BCS3678 are based on the Zebra DS3608-HP/ER and DS3678-HP/ER. The Guide is available to download from Zebra or from BARTEC: Zebra support download page: https://www.zebra.com/us/en/support-downloads.html Barcode Scanners Ultra Rugged Scanners – DS3608-HP/DS3678-HP and DS3608-ER/DS3678-ER BARTEC download page: http://automation.bartec.de/indexE.htm...

  • Page 78: Testing Communication/Data Transmission

    BCS36x8 Series Connection example Type 17-A1S4-*HP* and B7-A2S4-**** 15.1.4 Testing communication/data transmission The hand-held scanner BCS3608 is detected as HID device. The scanned data is transmitted as HID (Human Interface Device). The hand-held scanner functions in this mode as a keyboard entry. Testing communication/data transmission Open any program, such as Word, Notepad, Excel or other.
