Appendix A: Consumables —
needles and nozzles

Available nozzles and part numbers

• Available nozzles for contact dispensing (inner diameters):
• 0.10 mm.
• 0.15 mm.
• 0.30 mm (standard. Art. no. D16110020555).
• Available microvalves for contact and noncontact jetting. Threaded sleeve used for noncontact jetting where fluid is shot directly from
microvalve end.
• Available microvalve diameters:
• 0.10 mm.
• 0.15 mm.
• 0.20 mm.
• 0.30 mm (standard).
• 0.45 mm.
• 0.60 mm.
• Valve travel (stroke):
• 0.03 mm.
• 0.06 mm.
• 0.10 mm (standard).
• 0.15 mm.
