Cellink BIO X EMD User Manual page 44

05 Relevant G-code commands
Commands
G1 Xnnn Ynnn Ennn Fnnn
G1 Znnn Ennn Fnnn
G4 Snnn Pnnn
G7 Xnnn Ynnn Ennn Fnnn
G7 Znnn Ennn Fnnn
40
Description
When used in combination with the G90 command, which defines absolute coordinates, G1 is the abso-
lute move command. The values of the X and Y parameters are the coordinates (in mm) directing where
to move. E tells the BIO X to open the valve for extrusion. The F parameter is the speed of the printhead
in mm/min.
When used in combination with the G90 command, which defines absolute coordinates, G1 is the abso-
lute move command. The value for the Z parameter indicates the coordinate (in mm) directing where to
move. E tells the BIO X to open the valve for extrusion. The F parameter is the speed of the printhead in
mm/min.
The G4 command instructs the system to dwell. The S command is the wait time in seconds and P is the
wait time in milliseconds.
When used in combination with the G90 command, which defines absolute coordinates, G7 is the
relative move command. The values for the X and Y parameters are the coordinates (in mm) directing
where to move relative to the current position. E tells the BIO X to open the valve for extrusion. The F
parameter is the speed of the printhead in mm/min.
When used in combination with the G90 command, which defines absolute coordinates, G7 is the rela-
tive move command. The value for the Z parameter indicates the coordinate (in mm) directing where to
move relative to the current position. E tells the BIO X to open the valve for extrusion. The F parameter
is the speed of the printhead in mm/min.
