Removing Printhead - Cellink BIO X EMD User Manual

4.8 Removing printhead

1. Wipe any excess bioink from the nozzle tip using a delicate task wipe.
2. Cover the nozzle with the nozzle cover.
3. Depressurize the cartridge by detaching the airline from the printer (Figure 23A).
4. Remove the printhead from the BIO X. Use one hand to secure the printhead mount and the
other hand to remove the printhead.
5. Disconnect the tubing by twisting the cartridge adapter and lifting it off the cartridge (Figure
23B).
6. Twist and remove the cartridge. The Luer lock adapter will be removed in one piece with the
cartridge.
04 Getting started
35
