Planning
Planning Your PoE Configuration
HP ProCurve Switch
5300xl
HP ProCurve Switch
xl PoE modules
HP 600 RPS/EPS
Figure 3-7. Example of an HP 600 RPS/EPS Powering Two Modules
In this example there are two modules connected to the HP 600 RPS/EPS,
therefore each module will be supplied with 204 watts of PoE power to be
distributed to each modules 24 ports at 8.5 watts per port.
3-10
Std LED Mode PoE PoE EPS
Status
Link 1 Mode 2 3 4 5 6
PoE
hp procurve
PoE
xl module
J8161A 7 8 9 10 11 12
Source of Watts
Power Available
External PoE 204/each
Power module
Supply
PoE-Ready 10/100-TX Ports (1-24) – all ports are HP Auto-MDIX Std LED Mode
13 14 15 16 17 Link 18 Mode Link 1 Mode 2 3
PoE
hp procurve
xl
PoE
xl module
module
19 20 21 22 23 24 J8161A 7 8 9
# of Ports Powered and
Average Watts/Port
24 @ average 8.5 W each
PoE PoE EPS PoE-Ready 10/100-TX Ports (1-24) – all ports are HP Auto-MDIX
Status
4 5 6 13 14 15 16 17 Link 18 Mode
xl
module
10 11 12 19 20 21 22 23 24
Redundant # of Ports
Powered and Average Watts/
Port
None
