In-Chip Connectivity Between The Sp And Host Os Is Not Supported When Using Sideband Network Port Sharing - Oracle Sun Fire X4170 M2 Product Notes

Known Issues
2. When required, open the least number of Oracle ILOM Snapshot sessions, up to a
maximum of five Snapshot sessions. When running both CLI and web interface Snapshot
sessions, the maximum of five sessions can include CLI sessions and one web interface
session, or one session using the Oracle ILOM Remote System Console. Do not attempt to
open more than one web interface or Remote Console Snapshot sessions when also using
Snapshot CLI sessions.
3. When upgrading Oracle ILOM, use this command: load –source <PKG_URL>. When
issuing the command, if possible, use the the tftp, ftp, or sftp protocol rather than http or
https. Do not update Oracle ILOM using the web interface to upload the package file or to
provide the PKG_URL.
4. If the Oracle ILOM update fails, Oracle ILOM will reboot into the PreBoot utility. Use
these commands to recover:
Note -
a. Use the net config command to set the ipdiscover, managementport, and so on. Use
b. Use the net dhcp command to get the IP address if ipdiscovery is set to DHCP.
c. To flash Oracle ILOM, use this command: netflash <tftp-server-IP-address> <path-
In-chip connectivity between the SP and host OS is not
supported when using sideband network port sharing
Bug ID 15526839
When configured for sideband network port sharing, in-chip connectivity between the service
processor (SP) and the host operating system is not supported by the on-board host Gigabit
Ethernet controller.
Affected hardware and software:
Sun Fire X4170 M2 Server
■
Sun Fire X4270 M2 Server
■
Releases 1.0 through 1.10.1
■
Workaround:
Use a different port or route to transmit traffic between the source and destination targets
instead of using L2 bridging/switching.
38 Sun Fire X4170 M2 and X4270 M2 Servers Product Notes • July 2018
Use of the PreBoot utility is for Oracle Service personnel only.
the show command to list the configurations.
to-flash-file>
