Matrix Telecom Inverter System
Includes: 23" rack mount brackets (2), interconnection bus bars (3), busbar screws (8),
mounting screws (4), CAN cable for controller (1), DC power cable for controller (1),
Includes: 23" rack mount brackets (2), interconnection bus bars (5), busbar screws (5),
Includes: 23" rack mount brackets (2), interconnection bus bars (5), busbar screws (12),

Frame Assembly

Task 1 - Inverter Chassis Assembly

Step 1 - Change mounting brackets if required
12
100A STS/controller/interface Chassis
communications cable (1), 4-pin jumper (for CN1 if BMS is not used)
mounting screws (4), jumper (1), cable grommets (3)
The inverter chassis is pre-installed with 19-inch rack brackets.
For 23-inch rack mounting, replace the mounting brackets.
Copyright © 2008-2010 Eaton Corporation. All Rights Reserved.
IPN 997-00012-68D
50A MBS/PD Shelf
mounting screws (4)
100A MBS Shelf
February 2010
