Summary of Contents for Tree Frogs 7.0 Bengal Fort Double Decker

  • Page 2 All Slides: 125 Lbs. Tree Frogs recommends that the weight limits for all components must not be exceeded. Failure to adhere to these and other safety guidelines could result in damage to the swing set and/or injury to the users.
  • Page 3 Most cracks are not warrantable, however if you believe that the integrity of your play set is compromised by this natural occurrence, please contact the Tree Frogs Swing Set Dealer that you purchased your swing set from. We appreciate your purchase and know that you will enjoy your play system for many years to come.
  • Page 4 ● Depending on your experience, assembly of our play sets can take as little as 6 hours up to 24 hours, depending on size, after inventory of parts; therefore, we recommend you set aside a full two days for assembly. ● Identify all of the parts for your play set. Empty each box and lay out boards so you can see each part. Your instruction book will have detailed drawings that will make it easy for you to recognize individual parts. Keep all hardware and metal parts separate from wooden pieces.
  • Page 5 CONSUMER INFORMATION SHEET FOR PLAYGROUND SURFACING MATERIALS The U.S. Consumer Product Safety Commission (CPSC) estimates that about 100,000 playground equipment related injuries resulting from falls to the ground surface are treated annually in U.S. hospital emergency rooms. Injuries involving this hazard pattern tend to be among the most serious of all playground injuries, and have the potential to be fatal, particularly when the injury is to the head.

  • Page 6: Part Description

    BFU-8 16-4-00214 UNIVERSAL FORT CENTER UPRIGHT BFU-9 13-4-00068 UNIVERSAL 6- HOLE FACIA BFU-10 12-4-00141 UNIVERSAL RAIL BOTTOM 7.0 Bengal Fort Double Decker Bundle C. BDC-1 13-4-00076 UNIVERSAL FORT 4- HOLE FACIA BDC-2 16-4-00301 136” FORT CORNER POST BDC-3 17-4-00157 UNIVERSAL FORT MAINBEAM...
  • Page 7 Bengal Fort Tarp Bundle Item No. Part No. Part Description QTY. BTB-1 16-4-00284 UNIVERSAL FORT CENTER POST BTB-2 12-4-00145 UNIVERSAL TARP BOARD Bengal Fort Double Decker Tarp Bundle DTB-1 16-4-00311 FORT DOUBLE DECKER CENTER POST DTB-2 12-4-00145 UNIVERSAL TARP BOARD 7.0 Fort Rockwall Bundle RW-1 16-4-00308...
  • Page 8 Bengal Fort Wood Roof Bundle Item No. Part No. Part Description QTY. WRB-1 12-4-00206 BENGAL FORT WR SUPPORT (RIGHT) WRB-2 12-4-00207 BENGAL FORT WR SUPPORT (LEFT) WRB-3 10-4-00331 BENGAL FORT WR CENTER SUPPORT WRB-4 19-4-00084 BENGAL FORT WOOD ROOF BOARD WRB-5 10-4-00332 BENGAL FORT FAN BOARD #1...
  • Page 9 Bengal Fort Standard Box Item No. Part No. Part Description QTY. STB-1 59-1-00013 TREEFROGS PLAQUE STB-2 57-2-00004 1 1/4” PLAYGRIP SAFETY HANDLE STB-3 57-2-00005 1 1/4” PLAYGRIP LADDER HANDLE STB-4 56-1-00012 DUCTILE IRON SWING HANGER STB-5 59-1-00011 SPRING CLIPS- 10 X 100MM STB-6 58-1-00013 FORT LADDER BRACKET...
  • Page 10 Ben. Fort Double Decker Hdwr. Bag Item No. Item No. Part No. Part No. Part Description Part Description QTY. QTY. DDH-1 40-1-00002 1/2” ACORN NUT PLATED DDH-2 40-1-00013 1/2” X 7” CARRIAGE BOLT DDH-3 40-1-00028 1/2” HEX NUT DDH-4 40-1-00054 1/4”...
  • Page 11 7.0 Fort Rockwall Hardware Item No. Part No. Part Description QTY. RWH-1 40-1-00067 1/4” X 1 1/4” PAN PHILLIPS M/S RWH-2 40-1-00077 1/4” X 7/16” 4 PRONG T-NUT RWH-3 40-1-00081 1/4” USS FLATWASHER RWH-4 40-1-00061 3/8” X 5” HEX LAG SCREW RWH-5 40-1-00082 3/8”...
  • Page 12 Bengal Fort- Universal Bundle BFU-1 BFU-3 BFU-2 Universal Fort 4- Hole Facia Universal Fort Top Joist SB Universal Fort Mainbeam QTY. 7 QTY. 1 QTY. 2 BFU-4 BFU-5 BFU-6 Universal Fort Trapeze Arm Left Gusset Bracket Right Gusset Bracket QTY. 1 QTY.
  • Page 13 Bengal Fort- Universal Bundle BFU-10 Universal Rail Bottom QTY. 4 7.0 Bengal Fort Double Decker Bundle C. BDC-1 BDC-2 BDC-3 Universal Fort 4- Hole Facia 136” Fort Corner Post Universal Fort Mainbeam QTY. 4 QTY. 4 QTY. 2...
  • Page 14 7.0 Bengal Fort Double Decker Bundle C. BDC-4 BDC-6 BDC-5 Left Gusset Bracket Fort Double Decker Corner Post Right Gusset Bracket QTY. 2 QTY. 2 QTY. 2 BDC-7 BDC-8 BDC-9 Uni. Fort 8- Hole Facia Uni. Fort Top Joist Uni. Fort Center Upright QTY.
  • Page 15 7.0 Bengal Fort Double Decker Bundle C. BDC-13 BDC-14 BDC-15 Double Decker Rail Spindles 80” Fort Left Ladder Leg 80” Fort Right Ladder Leg QTY. 13 QTY. 1 QTY. 1 BDC-16 UDB-1 Uni. Fort Ladder Step Small Deck Board QTY. 5 QTY.
  • Page 16 Bengal Fort Tarp Bundle BTB-1 BTB-2 Universal Fort Center Post Universal Tarp Board QTT. 2 QTY. 3 Bengal Fort Double Decker Tarp Bundle DTB-1 DTB-2 Fort Double Decker Center Post Universal Tarp Board QTY. 2 QTY. 3...
  • Page 17 7.0 Fort Rockwall Bundle RW-1 RW-2 RW-3 107 1/2” Fort Left RW Ladder Leg 107 1/2” Fort Right RW Ladder Leg Uni. Fort RW Board w/ Rope Hole QTY. 1 QTY. 1 QTY. 1 RW-4 RW-5 RW-6 Uni. Fort RW Board Blank Uni.
  • Page 18 Fort Picnic Table Bundle PIC-1 PIC-3 PIC-2 Universal Deck Board- Slim Uni. Fort Picnic Table Board Uni. Fort Picnic Table Supports QTY. QTY. 4 QTY. 4 PIC-4 PIC-5 PIC-6 Uni. Fort Picnic Table Runner Uni. Fort Picnic Table Runner No Holes Uni.
  • Page 19 Universal Rail Bundle (Count Per Rail) RAIL-1 RAIL-2 RAIL-3 Universal Rail Top Universal Rail Bottom Universal Rail Spindle QTY. 1 QTY. 1 QTY. 5...
  • Page 20 Bengal Fort Wood Roof Bundle WRB-1 WRB-3 WRB-2 Bengal Fort WR Support (R) Bengal Fort WR Center Support Bengal Fort WR Support (L) QTY. 2 QTY. 2 QTY. 2 WRB-4 WRB-5 WRB-6 Bengal Fort WR Board Bengal Fort Fan Board #1 Bengal Fort Fan Board #2 QTY.
  • Page 21 Bengal Fort Wood Roof Bundle WRB-10 Uni. Fort WR Center Post QTY. 2 Double Decker Wood Roof Bundle DWR-1 DWR-2 DWR-3 Bengal Fort WR Support (R) Bengal Fort WR Support (L) Bengal Fort WR Center Support QTY. 2 QTY. 2 QTY.
  • Page 22 DWR-6 DWR-4 DWR-5 Bengal Fort Fan Board #1 DD WR Center Support Bengal Fort WR Board QTY. 2 QTY. 1 QTY. 17 DWR-7 DWR-8 DWR-9 Bengal Fort Fan Board #2 Bengal Fort Fan Board #3 Bengal Fort Fan Board #4 QTY.
  • Page 23 Bengal Fort Standard Box (Color Depends on Package) STB-1 STB-2 STB-3 STB-4 Treefrogs Plaque 1 1/4” Playgrip Saftey Handle 1 1/4” Playgrip Ladder Handles Ductile Iron Swing Hanger QTY. 1 QTY. 5 QTY. 2 QTY. 2 STB-5 STB-6 Spring Clips 10 x 100mm Fort Ladder Bracket QTY.
  • Page 24 Bengal Fort Double Decker Box (Color Depends on Package) DDB-1 DDB-2 DDB-3 DDB-4 19” Ship’s Wheel Binoculars Telescope 20” Trapeze Bar W/ Rings QTY. 1 QTY. 1 QTY. 1 QTY. 1...
  • Page 25 BENGAL FORT HARDWARE BAG INSTALLER NOTE: (YOU MUST ASSEMBLE THIS PRODUCT IN ACCORDANCE WITH THESE ASSEMBLY INSTRUCTIONS. WHEN COMPLETE GIVE MANUAL TO OWNER.) BFH-1 BFH-2 BFH-5 3/8” Acorn Nut Plated 1/2” Acorn Nut Plated 1/2” Hex Nut QTY. 4 QTY. 12 QTY.
  • Page 26 BENGAL FORT HARDWARE BAG INSTALLER NOTE: (YOU MUST ASSEMBLE THIS PRODUCT IN ACCORDANCE WITH THESE ASSEMBLY INSTRUCTIONS. WHEN COMPLETE GIVE MANUAL TO OWNER.) BFH-7 BFH-8 BFH-10 1/4” x 2” Hex Lag Screw 1/4” x 3” Hex Lag Screw 3/8” x 3 1/2” Hex Lag Screw QTY.
  • Page 27 BENGAL FORT HARDWARE BAG INSTALLER NOTE: (YOU MUST ASSEMBLE THIS PRODUCT IN ACCORDANCE WITH THESE ASSEMBLY INSTRUCTIONS. WHEN COMPLETE GIVE MANUAL TO OWNER.) BFH-16 BFH-17 BFH-18 BFH-19 1/4” USS Flatwasher 3/8” USS Flatwasher 1/2” USS Flatwasher 3/4” USS Flatwasher QTY. 75 QTY.
  • Page 28 BEN. FORT DOUBLE DECKER HARDWARE BAG INSTALLER NOTE: (YOU MUST ASSEMBLE THIS PRODUCT IN ACCORDANCE WITH THESE ASSEMBLY INSTRUCTIONS. WHEN COMPLETE GIVE MANUAL TO OWNER.) DDH-1 DDH-2 1/2” Acorn Nut Plated 1/2” x 7” Carriage Bolt QTY. 8 QTY. 8 DDH-3 DDH-4 DDH-5...
  • Page 29 BEN. FORT DOUBLE DECKER HARDWARE BAG INSTALLER NOTE: (YOU MUST ASSEMBLE THIS PRODUCT IN ACCORDANCE WITH THESE ASSEMBLY INSTRUCTIONS. WHEN COMPLETE GIVE MANUAL TO OWNER.) DDH-8 DDH-9 3/8” x 5” Hex Lag Screw #14 x 2” Pan Phillips T/S QTY. 6 QTY.
  • Page 30 DECK & RAIL HARDWARE BAGS INSTALLER NOTE: (YOU MUST ASSEMBLE THIS PRODUCT IN ACCORDANCE WITH THESE ASSEMBLY INSTRUCTIONS. WHEN COMPLETE GIVE MANUAL TO OWNER.) 2 1/2” Coated Deck Screw FORT PICNIC TABLE HARDWARE BAG PH-1 PH-2 2 1/2” Coated Deck Screw 1/4”...
  • Page 31 7.0 FORT ROCKWALL HARDWARE BAG INSTALLER NOTE: (YOU MUST ASSEMBLE THIS PRODUCT IN ACCORDANCE WITH THESE ASSEMBLY INSTRUCTIONS. WHEN COMPLETE GIVE MANUAL TO OWNER.) RWH-2 RWH-1 RWH-3 1/4” x 7/16” 4 Prong T-Nut 1/4” x 1 1/4” Pan Phillips M/S 1/4”...
  • Page 32 BENGAL FORT WOOD ROOF HARDWARE BAG INSTALLER NOTE: (YOU MUST ASSEMBLE THIS PRODUCT IN ACCORDANCE WITH THESE ASSEMBLY INSTRUCTIONS. WHEN COMPLETE GIVE MANUAL TO OWNER.) BRH-1 BRH-2 BRH-3 BRH-4 3/8” USS Flatwasher 1/2” USS Flatwasher 1/4” USS Flatwasher 1/4” x 3” Hex Lag Screw QTY.
  • Page 33 DOUBLE DECKER WOOD ROOF HARDWARE BAG INSTALLER NOTE: (YOU MUST ASSEMBLE THIS PRODUCT IN ACCORDANCE WITH THESE ASSEMBLY INSTRUCTIONS. WHEN COMPLETE GIVE MANUAL TO OWNER.) DWH-3 DWH-1 DWH-6 DWH-4 1/2” USS Flatwasher 3/8” USS Flatwasher 1/4” USS Flatwasher 1 5/8” Coated Deck Screw QTY.

  • Page 34: Parts Needed

    Rockwall Side Wall Assembly PARTS NEEDED HARDWARE NEEDED BDC-2- 136” Fort Corner Post- (2) BFH-10- 3/8” x 3 1/2” Hex Lag Screw- BFH-17- 3/8” USS Flatwasher- BDC-8- Uni. Fort Top Joist- BFH-3- 1/2” x 7” Carriage Bolt- BFH-19- 3/4” USS Flatwasher- BFU-1- Uni.
  • Page 35 Rockwall Side Wall Assembly SB Side Wall Assembly PARTS NEEDED HARDWARE NEEDED BFU-5- Left Gusset Bracket- BFH-3- 1/2” x 7” Carriage Bolt- BFH-19- 3/4” USS Flatwasher- BFU-6- Right Gusset Bracket- BFH-18- 1/2” USS Flatwasher- BFH-15- 1/2” Split Lockwasher- BFU-8- Uni. Fort Center Upright- BFH-5- 1/2”...
  • Page 36 SB Side Wall Assembly PARTS NEEDED HARDWARE NEEDED BDC-2- 136” Fort Corner Post- BFH-10- 3/8” x 3 1/2” Hex Lag Screw- BFH-17- 3/8” USS Flatwasher- BFU-1- UNI. Fort 4- Hole Facia- BFH-3- 1/2” x 7” Carriage Bolt- BFH-19- 3/4” USS Flatwasher- BFU-2- Uni.
  • Page 37 SB Side Wall Assembly Uni. Rail assembly (Count Per Rail) PARTS NEEDED HARDWARE NEEDED BFU-5- Left Gusset Bracket- BFH-17- 3/8” USS Flatwasher- BFH-10- 3/8” x 3 1/2” Hex Lag Screw- BFU-6- Right Gussets Bracket- (1) BFH-3- 1/2” x 7” Carriage Bolt- BFH-19- 3/4”...
  • Page 38 Rockwall Assembly PARTS NEEDED HARDWARE NEEDED RW-1- 107 1/2” Fort Left RW Ladder Leg- RWH-1- 1/4” x 1 1/4” Pan Phillips M/S- (40) RW-2- 107 1/2” Fort Right RW Ladder Leg- RWH-2- 1/4” x 7/16” 4 PRong T-Nut- (40) RW-3- Uni. Fort RW Board w/ Rope Hole- RWH-3- 1/4”...
  • Page 39 Picnic Seat Assembly Universal Deck Assembly PARTS NEEDED HARDWARE NEEDED UDB-1- Small Deck Board- (16) UDB-2- Large Deck Board- (12) PH-1- 2 1/2” Coated Deck Screw- (36) UDB-3- Universal Deck Runner- UDB-4- Universal Deck Support- UDH-1- 2 1/2” Coated Deck Screw- (84) PIC-1- Uni.
  • Page 40 Picnic Table Assembly Bengal Main Assembly PARTS NEEDED HARDWARE NEEDED PIC-3- Uni. Fort Picnic Tabel Board- PH-1- 2 1/2” Coated Deck Screw- (45) PIC-4- Uni. Fort Picnic Table Runner- BFH-10- 3/8” x 3 1/2” Hex Lag Screw- (16) PIC-5- Uni. Fort Picnic Table Runner No Holes- (1) BFH-17- 3/8”...
  • Page 41 Bengal Main Assembly PARTS NEEDED HARDWARE NEEDED Uni. Deck Assembly- BFH-9- 1/4” x 4 1/2” Hex Lag Screw- (16) BFU-7- Uni. Fort 8-Hole Facia- BFH-16- 1/4” USS Flatwasher- (16) BFH-10- 3/8” x 3 1/2” Hex Lag Screw- BFH-17- 3/8” USS Flatwasher-...
  • Page 42 Bengal Main Assembly PARTS NEEDED HARDWARE NEEDED BFU-9- Universal 6 Hole Facia- BFH-17- 3/8” USS Flatwasher- (14) BTB-1- Universal Fort Tarp Center Post- BFH-10- 3/8” x 3 1/2” Hex Lag Screw- (12) BFH-11- 3/8” x 5” Hex Lag Screw- Skip Step if you have a Wood Roof...
  • Page 43 Bengal Fort Wood Roof PARTS NEEDED HARDWARE NEEDED WRB-10- Uni. Fort Wood Roof Center Post- BFH-17- 3/8” USS Flatwasher- BFH-10- 3/8” x 3 1/2” Hex Lag Screw- BFH-11- 3/8” x 5” Hex Lag Screw-...
  • Page 44 Bengal Main Assembly PARTS NEEDED HARDWARE NEEDED BFH-8- 1/4” x 3” Hex Lag Screw- BFU-10- Universal Rail Bottom- BFH-9- 1/4” x 4 1/2” Hex Lag Screw- Universal Rail- BFH-7- 1/4” x 2” Hex Lag Screw- BFH-16- 1/4” USS Flatwasher- (12)
  • Page 45 Bengal Main Assembly PARTS NEEDED HARDWARE NEEDED RW-8- Universal Entrapment Block- RWH-4- 3/8” x 5” Hex Lag Screw- Rockwall Assembly- RWH-5- 3/8” USS Flatwasher-...
  • Page 46 Bengal Main Assembly Bengal Tarp Assembly PARTS NEEDED HARDWARE NEEDED RW-7- Universal Rope Block- RWH-4- 3/8” x 5” Hex Lag Screw- BTB-2- Universal Tarp Board- RWH-5- 3/8” USS Flatwasher- BFH-9- 1/4” x 4 1/2” Hex Lag Screw- BFH-16- 1/4” USS Flatwasher-...

  • Page 47: Tarp Installation

    Tarp Installation HARDWARE NEEDED HARDWARE NEEDED Tarp Snaps with Tarp- Take one corner of the VINYL TARP and place it flush in the corner. Tap the snap with a blunt object, leaving an indention of the snap in the wood. Repeat this process until all the snaps have been indented in the wood on both side.
  • Page 48 Bengal Fort Wood Roof PARTS NEEDED HARDWARE NEEDED WRB-5- Ben Fort Fan Board #1- BRH-5- 1 5/8” Coated Deck Screw- (48) WRB-6- Ben Fort Fan Board #2- BRH-7- 3/8” x 5 1/2” Carriage Bolt- WRB-7- Ben Fort Fan Board #3- BRH-3- 1/2”...
  • Page 49 Bengal Fort Wood Roof PARTS NEEDED HARDWARE NEEDED BRH-5- 1 5/8” Coated Deck Screws- (60) Fan Assembly- WRB-3- Bengal Fort WR Center Support- WRB-4- Bengal Fort Wood Roof Board- Repeat for both sides of Wood Roof 1 1/2” Overhang...
  • Page 50 Bengal Fort Wood Roof PARTS NEEDED HARDWARE NEEDED WRB-4- Bengal Fort Wood Roof Board- (12) BRH-5- 1 5/8” Coated Deck Screw- (76) WRB-9- Universal WR Peak Facia- Repeat for both sides of Wood Roof...
  • Page 51 Bengal Main Assembly PARTS NEEDED HARDWARE NEEDED PIC-2- Uni. Fort Picnic Table Supports- PH-3- 3/8” x 3 1/2” Hex Lag Screw- Picnic Seat Assembly- PH-5- 3/8” USS Flatwasher- PH-2- 1/4” x 4 1/2” Hex Lag Screw- PH-4- 1/4” USS Flatwasher-...
  • Page 52 Bengal Main Assembly PARTS NEEDED HARDWARE NEEDED PIC-2- Uni. Fort Picnic Table Supports- (2) PH-3- 3/8” USS Flatwasher- PH-4- 1/4” USS Flatwasher- PH-2- 1/4” x 4 1/2” Hex Lag Screw- PH-5- 3/8” x 3 1/2” Hex Lag Screw- There is a 22” gap from the ground to the bottom of the support...
  • Page 53 Double Decker Wall Assembly PARTS NEEDED HARDWARE NEEDED BDC-1- Uni. Fort 4- Hole Facia- DDH-12- 3/8” USS Flatwasher- DDH-7- 3/8” x 3 1/2” Hex Lag Screw- BDC-6- Fort DD Corner Post- DDH-2- 1/2” x 7” Carriage Bolt- DDH-14- 3/4” USS Flatwasher- BDC-3- Uni.
  • Page 54 Double Decker Wall Assembly PARTS NEEDED HARDWARE NEEDED BDC-4- (L) Gusset Bracket- DDH-12- 3/8” x 3 1/2” Hex Lag Screw- DDH-7- 3/8” USS Flatwasher- BDC-5- (R) Gusset Bracket- DDH-2- 1/2” x 7” Carriage Bolt- DDH-14- 3/4” USS Flatwasher- BDC-9- Uni. Fort Center Upright- DDH-13- 1/2 USS Flatwasher- DDH-10- 1/2”...
  • Page 55 Double Decker Ladder Double Decker Rail PARTS NEEDED HARDWARE NEEDED DDH-6- 1/4” x 4 1/2” Hex Lag Screw- (20) BDC-16- Uni. Fort Ladder Step- DRH-1- 2 1/2” Coated Deck Screw- (52) BDC-14- Fort Left Ladder Leg- BDC-15- Fort Right Ladder Leg- BDC-11- Double Decker Rail Bottom- BDC-12- Double Decker Rail Bottom- BDC-13- Double Decker Rail Spindle-...
  • Page 56 Double Decker Assembly PARTS NEEDED HARDWARE NEEDED BDC-3- Universal Fort Mainbeam- DDH-2- 1/2” x 7” Carriage Bolt- DDH-14- 3/4” USS Flatwasher- DDH-13- 1/2” USS Flatwasher- DDH-10- 1/2” Split Lockwasher- DDH-3- 1/2” Hex Nut- DDH-1- 1/2” Acorn Nut Plated- Fort this step we need to clamp the BDC-3 at 57 1/2” to the Bengal Corner Posts and drill a 9/16”...
  • Page 57 Double Decker Assembly PARTS NEEDED HARDWARE NEEDED BDC-7- Universal Fort 8 Hole Facia- DDH-7- 3/8” x 3 1/2” Hex Lag Screw- DDH-12- 3/8” USS Flatwasher-...
  • Page 58 Double Decker Assembly PARTS NEEDED HARDWARE NEEDED Universal Deck- DDH-11- 1/4” USS Flatwasher- (18) BFU-10- Universal Rail Bottom- DDH-6- 1/4” x 4 1/2” Hex Lag Screw- (16) DDH-4- 1/4” x 3” Hex Lag Screw-...
  • Page 59 Double Decker Assembly PARTS NEEDED PARTS NEEDED HARDWARE NEEDED HARDWARE NEEDED Ladder Assembly- DDH-12- 3/8” USS Flatwasher- (10) BDC-10- Universal 6 Hole Facia-...
  • Page 60 Double Decker Assembly PARTS NEEDED HARDWARE NEEDED DTB-1- Double Decker Tarp Center Post- DDH-12- 3/8” USS Flatwasher- BDC-11- Double Decker Rail Bottom- DDH-8- 3/8” x 5” Hex Lag Screw- DDH-7- 3/8” x 3 1/2” Hex Lag Screw- DDH-11- 1/4” USS Flatwasher- DDH-5- 1/4”...
  • Page 61 Double Decker Wood Roof PARTS NEEDED HARDWARE NEEDED DWR-11- Universal Fort WR Center Post- DDH-12- 3/8” USS Flatwasher- DDH-7- 3/8” x 3 1/2” Hex Lag Screw- DDH-8- 3/8” x 5” Hex Lag Screw-...
  • Page 62 Double Decker Assembly PARTS NEEDED HARDWARE NEEDED Double Decker Rail- DDH-6- 1/4” x 4 1/2” Hex Lag Screw- (10) Uni. Rail Assembly- DDH-11- 1/4” USS Flatwasher- (20) DDH-4- 1/4” x 2” Hex Lag Screw- (10)
  • Page 63 Double Decker Wood Roof PARTS NEEDED HARDWARE NEEDED DWH-8- 3/8” x 5 1/2” Carriage Bolt- DWH-3- 1/2” USS Flatwasher- DWR-1- Bengal Fort WR Support (R)- DWH-1- 3/8” USS Flatwasher- DWH-9- 3/8” Split Lockwasher- DWR-2- Bengal Fort WR Support (L)- DWH-10- 3/8” Hex Nut- DWH-11- 3/8”...
  • Page 64 Double Decker Wood Roof PARTS NEEDED HARDWARE NEEDED Fan Assembly- DWH-6- 1 5/8” Coated Deck Screws- (40) DWR-4- Bengal Fort Wood Roof Board- DWR-3- Bengal Fort WR Center Support-...
  • Page 65 Double Decker Wood Roof PARTS NEEDED HARDWARE NEEDED DWR-5- Bengal Fort WR Board- (10) DWH-6- 1 5/8” Coated Deck Screws- (50) DWR-4- DD WR Center Support-...
  • Page 66 Double Decker Wood Roof PARTS NEEDED HARDWARE NEEDED DWR-5- Bengal Fort WR Board- DWH-6- 1 5/8” Coated Deck Screw- (19) DWR-10- Universal WR Peak Facia- DWR-10...
  • Page 67 Double Decker Tarp Assembly PARTS NEEDED HARDWARE NEEDED DTB-2- Universal Tarp Board- DDH-11- 1/4” USS Flatwasher- DDH-6- 1/4” x 4 1/2” Hex Lag Screw-...
  • Page 68 Double Decker Tarp Assembly Accessory Installs PARTS NEEDED HARDWARE NEEDED Double Decker Tarp- BFH-13- #14 x 1 1/4” Pan Phillips T/S- Slide- BFH-16- 1/4” USS Flatwasher- Repeat the tarp install process from before.
  • Page 69 Accessory Installs PARTS NEEDED HARDWARE NEEDED Wave Slide- BFH-20- #14 x 2” Pan Phillips T/S- STB-2- 1 1/4” Playgrip Safety Handle- BFH-16- 1/4” USS Flatwasher-...
  • Page 70 Accessory Installs PARTS NEEDED HARDWARE NEEDED STB-2- 1 1/4” Playgrip Safety Handle- BFH-20- #14 x 2” Pan Phillips T/S- (10) STB-3- 1 1/4” Plagrip Ladder Handle- BFH-16- 1/4” USS Flatwasher- (10)
  • Page 71 Accessory Installs PARTS NEEDED HARDWARE NEEDED STB-6- Fort Ladder Bracket- BFH-10- 3/8” x 3 1/2” Hex Lag Screw- DDB-2- Binoculars w Hardware- BFH-17- 3/8” USS Flatwasher-...
  • Page 72 Accessory Installs PARTS NEEDED HARDWARE NEEDED DDB-1- 19” Ship’s Wheel- Hardware w/ Accessories BBD-3- Telescope-...
  • Page 73 Accessory Installs PARTS NEEDED HARDWARE NEEDED STB-5- Spring Clip- 10 x 100mm- None DDB-4- 20” Trapeze Bar w/ Rings-...
  • Page 74 Extended Monkey Bar Installation Manual Version 1:20 Sections Section 1: Cover & Liability Info Section 2: Product Parts Section 3: Sub-Assemblies 4465 West Sam Houston Parkway N. Section 4: Main Assebmly Houston, Texas 77041 WWW.TREEFROGSSHOWROOMS.COM © 2018 KID STRUCTURES INC.

  • Page 75: Important - Please Read

    Most cracks are not warrantable, however if you believe that the integrity of your play set is compromised by this natural occurrence, please contact the Tree Frogs Swing Set Dealer that you purchased your swing set from. We appreciate your purchase and know that you will enjoy your play system for many years to come.
  • Page 76 ● Depending on your experience, assembly of our play sets can take as little as 6 hours up to 24 hours, depending on size, after inventory of parts; therefore, we recommend you set aside a full two days for assembly. ●...
  • Page 77 ● Be sure that the sealant you select is non-toxic and child safe. Your local Tree Frogs Wooden Swing Set Factory dealer may offer a complete power wash and reseal and maintenance program.
  • Page 78 Rock Wall: 150 Lbs. All Slides: 125 Lbs. Tree Frogs recommends that the weight limits for all components must not be exceeded. Failure to adhere to these and other safety guidelines could result in damage to the swing set. and/or injury to the users.
  • Page 79 CONSUMER INFORMATION SHEET FOR PLAYGROUND SURFACING MATERIALS The U.S. Consumer Product Safety Commission (CPSC) estimates that about 100,000 playground equipment related injuries resulting from falls to the ground surface are treated annually in U.S. hospital emergency rooms. Injuries involving this hazard pattern tend to be among the most serious of all playground injuries, and have the potential to be fatal, particularly when the injury is to the head.
  • Page 80 And for a period of 1-Year Tree Frogs warranties all ropes, structural foam molded slides to be free of defects in material and workmanship. Fading is not considered a defect and may occur with seasonal and geographical conditions.
  • Page 81 Extended Monkey Bar (032) Description QTY. (CC-220) 032-1 31 1/4” Monkey Bar Bottom (CC-136) 032-2 26 1/2” Step (CC-149) 032-3 19” Left Gusset (CC-148) 032-4 19” Right Gusset (CC-190) 032-5 16” Left MB Gusset (CC-191) 032-6 16” Right MB Gusset (CC-193) 032-7 103”...
  • Page 82 Extended Monkey Bar (032) Description QTY. (CC-192) 032-8 103” Right Support 032-9 119 1/2” (R) Monkey Bar Overhead 032-10 119 1/2” (L) Monkey Bar Overhead...
  • Page 83 EXTENDED MONKEY BAR -032-HWR-BAG INSTALLER NOTE: (YOU MUST ASSEMBLE THIS PRODUCT IN ACCORDANCE WITH THESE ASSEMBLY INSTRUCTIONS. WHEN COMPLETE GIVE MANUAL TO OWNER.) MB-2 MB-1 1/2” x 7” Cariage Bolt 1/2” Acorn Nut Plated QTY. 4 QTY. 4 MB-3 1/2” Hex Nut QTY.
  • Page 84 EXTENDED MONKEY BAR -032-HWR-BAG INSTALLER NOTE: (YOU MUST ASSEMBLE THIS PRODUCT IN ACCORDANCE WITH THESE ASSEMBLY INSTRUCTIONS. WHEN COMPLETE GIVE MANUAL TO OWNER.) MB-5 1/2 x 9” Hex Bolt QTY. 1 MB-6 MB-7 1/4” x 3” Hex Lag Screw 1/4” x 4 1/2” Hex Lag Screw QTY.
  • Page 85 EXTENDED MONKEY BAR -032-HWR-BAG INSTALLER NOTE: (YOU MUST ASSEMBLE THIS PRODUCT IN ACCORDANCE WITH THESE ASSEMBLY INSTRUCTIONS. WHEN COMPLETE GIVE MANUAL TO OWNER.) MB-10 MB-12 MB-13 #14 x 2” Pan Phillip T/S MB-11 1/2” Split Lockwasher 1/4” Uss Flatwasher 2” Metal Tap Screw QTY.
  • Page 86 Extended Monkey Bar-032-HWA-SB Description QTY. 032-A 1 1/4” x 22 1/4” PlayGrip Tube 032-B PlayGrip Ladder Handle...

  • Page 87: Parts Needed

    Monkey Bar Support - Sub Assemblies PARTS NEEDED HARDWARE NEEDED CC-220- Monkey Bar Bottom- MB-7- 1/4”x4 1/2” Hex Lag Screw ZP- (16) MB-9 3/8” x 5” Hex Lag Screw ZP- CC-136- Step- MB-13- 1/4” Uss Flatwasher ZP- (16) MB-14 3/8” Uss Flatwasher ZP- CC-192- Right Support Leg- MB-10- #14 x 2”...
  • Page 88 Extended Monkey Bar Overhead Extended Monkey Bar Assembly PARTS NEEDED HARDWARE NEEDED 032-9- (R) Monkey Bar Overhead- MB-11- 2” Metal Tap Screw- (12) MB-2- 1/2” x 7” Carriage Bolt- 032-8- (L) Monkey Bar Overhead- MB-16- 3/4” USS Flatwasher- MB-15- 1/2” USS Flatwasher- 032-A 1 1/4”Diax 16 ga x22”...

  • Page 89: Monkey Bar Assembly

    Monkey Bar Assembly PARTS NEEDED HARDWARE NEEDED Monkey Bar Overhead Assembly (1) MB-1- 1/2”-13 Acorn Nut Plated- MB-2- 1/2”-13 x 7” Carriage Bolt- Support Assembly MB-8- 3/8” x 3 1/2” Hex Lag Screw- MB-3- 1/2”-13 Hex Nut- CC-190 Left MB Gusset MB-12- 1/2”...
  • Page 90 5.8 Jaguar Fort Monkey Bar Assembly 5.8 Jaguar Playcenter Monkey Bar Assembly PARTS NEEDED HARDWARE NEEDED Monkey Bar Assembly MB-1- 1/2”-13 Acorn Nut Plated- MB-2- 1/2”-13 x 7” Carriage Bolt- CC-149 Left Gusset (1) MB-3- 1/2”-13 Hex Nut- MB-5- 1/2”-16 x 9” Hex Bolt- CC-148 Right Gusset (1) MB-8- 3/8”...
  • Page 91 6.5 & 7.5 Monkey Bar Assembly HARDWARE NEEDED MB-1- 1/2”-13 Acorn Nut Plated- MB-2- 1/2”-13 x 7” Cariage Bolt- MB-3- 1/2”-13 Hex Nut- MB-12- 1/2” Split Lockwasher- MB-15- 1/2” Uss Flatwasher- MB-16- 3/4” Uss Flatwasher- Set the Monkey Bar overhead on the deck(Fort) or line up the bottom of the Monkey Bar Overhead with the top of the Deck(Playcenter) and insert Monkey Bar Overhead in between the Corner Post and the Center Post.
  • Page 92 Extended Loft Installation Manual Version 1:19 Sections Section 1: Cover & Liability Info Section 2: Product Parts Section 3: Sub-Assemblies 4465 West Sam Houston Parkway N. Section 4: Main Assebmly Houston, Texas 77041 Section 5: Roof Options WWW.TREEFROGSSHOWROOMS.COM © 2018 KID STRUCTURES INC.
  • Page 93 Most cracks are not warrantable, however if you believe that the integrity of your play set is compromised by this natural occurrence, please contact the Tree Frogs Swing Set Dealer that you purchased your swing set from. We appreciate your purchase and know that you will enjoy your play system for many years to come.
  • Page 94 ● Depending on your experience, assembly of our play sets can take as little as 6 hours up to 24 hours, depending on size, after inventory of parts; therefore, we recommend you set aside a full two days for assembly. ●...
  • Page 95 ● Be sure that the sealant you select is non-toxic and child safe. Your local Tree Frogs Wooden Swing Set Factory dealer may offer a complete power wash and reseal and maintenance program.
  • Page 96 Rock Wall: 150 Lbs. All Slides: 125 Lbs. Tree Frogs recommends that the weight limits for all components must not be exceeded. Failure to adhere to these and other safety guidelines could result in damage to the swing set. and/or injury to the users.
  • Page 97 CONSUMER INFORMATION SHEET FOR PLAYGROUND SURFACING MATERIALS The U.S. Consumer Product Safety Commission (CPSC) estimates that about 100,000 playground equipment related injuries resulting from falls to the ground surface are treated annually in U.S. hospital emergency rooms. Injuries involving this hazard pattern tend to be among the most serious of all playground injuries, and have the potential to be fatal, particularly when the injury is to the head.
  • Page 98 And for a period of 1-Year Tree Frogs warranties all ropes, structural foam molded slides to be free of defects in material and workmanship. Fading is not considered a defect and may occur with seasonal and geographical conditions.
  • Page 99 KSI-046 Extended Loft Lumber Description QTY. (CC-021) 046-1 28” Spiral Slide Filler 046-2 89 1/4” 4- Hole Facia (CC-062) 046-3 32” Entrapment Facia (CC-088) 046-4 27 1/2” Rail Spindle (CC-099) 046-5 25” Rail Top (CC-101) 046-6 25” Universal Filler (CC-102) 046-7 25”...
  • Page 100 KSI-046 Extended Loft Lumber Description QTY. (CC-100) 046-8 25” Rail Bottom (CC-109) 046-9 32” Deck Board (CC-112) 046-10 53” Top Joist 046-11 89 1/4” Tarp Center 046-12 92” Tarp Side Facia (CC-138) 046-13 25” Entrapment Board (CC-139) 046-14 32” Deck Board...
  • Page 101 KSI-046 Extended Loft Lumber Description QTY. (CC-140) 046-15 32” 6- Hole Facia 046-16 89 1/4” 8- Hole Facia (CC-141) 046-17 25” Entrapment Board (CC-181) 046-18 32 5/16” Tarp Upright (CC-180) 046-19 41” Center Upright (CC-179) 046-20 46” Corner Post (CC-194) 046-21 25”...
  • Page 102 Description QTY. KSI-047 Extended Loft Wood Roof Lumber (CC-197) 047-1 6 5/16” Short Fan Board (CC-006) 047-2 8 7/16” Center Fan Board (CC-022) 047-3 28 3/4” Bottom Fan Board (CC-055) 047-4 11 1/16” Peak Support (CC-056) 047-5 11 7/16” Fan Cap (CC-110) 047-6 39 3/8”...
  • Page 103 Description QTY. KSI-047 Extended Loft Wood Roof Lumber 047-8 92” Wood Roof Board...
  • Page 104 EXTENDED LOFT - 047- HWR-BAG INSTALLER NOTE: (YOU MUST ASSEMBLE THIS PRODUCT IN ACCORDANCE WITH THESE ASSEMBLY INSTRUCTIONS. WHEN COMPLETE GIVE MANUAL TO OWNER.) 1/4”x3” Hex Lag Screw ZP 1/4”x 4 1/2” Hex Lag Screw QTY. 17 QTY; 37 3/8” x 3 1/2” Hex Lag Screw 3/8”...
  • Page 105 KSI-047 EXTENDED LOFT WOOD ROOF HARDWARE INSTALLER NOTE: (YOU MUST ASSEMBLE THIS PRODUCT IN ACCORDANCE WITH THESE ASSEMBLY INSTRUCTIONS. WHEN COMPLETE GIVE MANUAL TO OWNER.) WR-1 WR-4 WR-2 WR-3 3/8” Acorn Nut Plated 1 5/8”Coated Deck Screw 3/8” x 3” Carriage Bolt ZP 1 1/2”...
  • Page 106 KSI-046 Extended Loft Accessories Description QTY. 046-A Bubble Panel 046-B Binocul;ar...

  • Page 107: Parts Needed

    Extended Loft- Sub Assemblies PARTS NEEDED HARDWARE NEEDED CC-088- Rail Spindle- (20) CC-099- Universal Rail Top- B- #8 x 2 1/2” Coated Deck Screw- (180) CC-100- Rail Bottom- CC-102- Deck Runner- CC-109- Deck Board- CC-139- Deck Board- Make 3 of these Assemblies Make 6 of these Assemblies...
  • Page 108 Extended Loft -Sub Assemblies PARTS NEEDED HARDWARE NEEDED CC-062- Entrapment Board- CC-112- Top Joist- A-6- 3/8” USS Flatwasher- (24) CC-140- 6-Hole Facia- CC-179- Corner Post- A-3- 3/8” x 3 1/2” Hex Lag Screw- (20) CC-194- Entrapment Block- 046-A- Bubble Panel- A-5- 3/8”...
  • Page 109 Extended Loft Deck Assemblies PARTS NEEDED HARDWARE NEEDED Deck Assembly- A-2- 1/4”x 4 1/2” Hex Lag Screw- CC-101- Universal Filler- A-5- 1/4” Uss Flatwasher- Make 2 of these Assemblies...
  • Page 110 5’ & 5.8 Loft Playcenter 6.5 & 7.5 Loft PARTS NEEDED HARDWARE NEEDED CC-101- Universal Filler- A-2- 1/4” x 4 1/2” Hex Lag Screw- A-3- 3/8” x 3 1/2” Hex Lag Screw- CC-138- Entrapment Board- A-5- 1/4” Uss Flatwasher- A-6- 3/8” Uss Flatwasher- CC-141- Entrapment Board-...
  • Page 111 Fort -Loft Assembly PARTS NEEDED HARDWARE NEEDED CC-101- Universal Filler- A-2- 1/4” x 4 1/2” Hex Lag Screw- CC-138- Entrapment Board- A-3- 3/8” x 3 1/2” Hex Lag Screw- CC-141- Entrapment Board- A-5- 1/4” Uss Flatwasher- A-6- 3/8” Uss Flatwasher- 5.8 Bengal Fort 6.5 &...
  • Page 112 Extended Loft Assembly PARTS NEEDED HARDWARE NEEDED Entrance Assembly- Bubble Panel Assembly- CC-180- Center Upright- 046-16- 8- Hole Facia- 89 1/4” 25 1/4 25 1/4 25 1/4...
  • Page 113 Extended Loft Assembly PARTS NEEDED HARDWARE NEEDED 046-2- 4- Hole Facia- A-3- 3/8” x 3 1/2” Hex Lag Screw- Rail Assembly- A-6- 3/8” USS Flatwasher- A-1- 1/4” x 3” Hex Lag Screw- (12) A-5- 1/4” USS Flatwasher- (24) A-2- 1/4” x 4 1/2” Hex Lag Screw- (12)
  • Page 114 Extended Loft Tarp Assembly PARTS NEEDED HARDWARE NEEDED CC-181- Tarp Upright- A-3- 3/8” x 3 1/2” Hex Lag Screw- 046-11- Tarp Center- A-6- 3/8” USS Flatwasher- 046-12- Tarp Side Facia- A-2- 1/4” x 4 1/2” Hex Lag Screw- A-5- 1/4” USS Flatwasher- B- 2 1/2”...
  • Page 115 Extended Loft Tarp Assembly PARTS NEEDED HARDWARE NEEDED Tarp with Hardware Hardware with Tarp (Figure A.)- Take one corner of the VINYL TARP and place it flush in the corner. Tap the snap with a blunt object, leaving an indention of the snap in the wood. Repeat this process until all the snaps have been indented in the wood on both sides of the Playcenter.
  • Page 116 Wood Roof Assembly PARTS NEEDED HARDWARE NEEDED CC-110- Wood Roof Support- WR-2- 3/8” x 3” Carriage Bolt- WR-15- 1/2” USS Flatwasher- CC-055- Peak Support- WR-14- 3/8” USS Flatwasher- WR-12- 1/2” Split Lockwasher- WR-7- 3/8” Hex Nut- WR-1- 3/8” Acorn Nut Plated- WR-4- 1 5/8”...
  • Page 117 Wood Roof Assembly PARTS NEEDED HARDWARE NEEDED 047-7- Center Wood Roof Support- WR-14- 3/8” USS Flatwasher- CC-110- Wood Roof Support- WR-10- 3/8” USS Flatwasher- CC-055- Peak Support- WR-4- 1 5/8” Coated Deck Screw- WR-5- 2 1/2” Coated Deck Screw-...
  • Page 118 Wood Roof Assembly PARTS NEEDED HARDWARE NEEDED CC-197- Short Fan Board- WR-4- 1 5/8” Coated Deck Screw- (24) CC-006- Center Fan Board- WR-3- 1 1/2” Coated Deck Screw- (20) CC-022- Bottom Fan Board- CC-056- Fan Cap- Make 2 Wood Roof Fans...
  • Page 119 Wood Roof Assembly PARTS NEEDED HARDWARE NEEDED 047-8- Wood Roof Board- (18) WR-11- 3/8” T-Nut- WR-14- 3/8” USS Flatwasher- WR-8- 3/8” x 1/2” Hex Nut- WR-4- 1 5/8” Coated Deck Screw- (144) Repeat for Both Sides of Loft Repeat for Both Sides of Loft...
  • Page 120 Extended Loft...
  • Page 121 Super 360 Spiral Slide Installation Manual Version 1:19 Sections Page 1: Part List Page 2: 5.8’ Deck Height Assembly Page 3: 5’ & 7’ Deck Height Assembly 4465 West Sam Houston Parkway N. Houston, Texas 77041 Page 4: 6.5’ Deck Height Assembly WWW.TREEFROGSSHOWROOMS.COM ©...
  • Page 122 PARTS 3/8” x 5” 5/16” x 1 1/2” Lag Screw Lag Screw QTY. 2 QTY. 26 5/16” x 1” Hex Bolt QTY. 99 5/16”-18 Lock Nut QTY. 97 5/16” Flatwasher QTY. 222 3/8” Flatwasher QTY. 2...
  • Page 123 Quick Reference Guide #1 For 5.8’ Deck Height 1) Turn 10° 1 Bolt Hole CCW 2) Turn 30° 1 Bolt Hole CCW 3) Turn 90° Elbow 0 Bolt Hole to even seam 4) Turn 90° Elbow 2 Bolt Holes CW 5) Turn 90°...
  • Page 124 Quick Reference Guide #2 For 5’ & 7’ Deck Heights 1) Turn 10° 1 Bolt Hole CW 2) Turn 30° 0 Bolt Hole With Even Seem 3) Turn 90° 1 Bolt Hole CW 5) Turn 90° Elbow 2 Bolt Holes CW 4) Turn 90°...
  • Page 125 Quick Reference Guide #3 For 6.5’ Deck Height 1) Turn 10° 1 Bolt Hole CCW 2) Turn 30° 2 Bolt Hole CW 3) Turn 90° Elbow 1 Bolt Hole CW 4) Turn 90° Elbow 2 Bolt Holes CCW 5) Turn 90° Elbow 2 Bolt Holes 6) Attach Exit Chute Level To Ground...
  • Page 126 Step #1 Assemble the Elbow Section Halves together with the hardware as shown. Note the position of the Overlap Flanges in relation to the direction of the Bolts. 90 Section RH Lock Nut Washer Overlap Flanges 90 Section LH Bolt Washer...
  • Page 127 Step #2 Using Nuts, Washers and Bolts, attach the 10 Elbow to Entry Panel in the "Quick Reference" orientation. Step #3 After properly blocking the slide entrance on the playset, attach the Entry Chute/first Elbow assembly to the playset with the Lag Screws and Washers provided. Step #4 Bolt Washer...
  • Page 128 Step #5 Using Nuts, Washers and Bolts, attach the 90 Elbow to the previous Elbow in the "Quick Reference" orientation. Step #6 Using Nuts, Washers and Bolts, attach the 2nd 90 Elbow to the previous Elbow in the "Quick Reference" orientation.
  • Page 129 Step #8 Place the end of the Exit Chute up against the last Elbow Section and make it level with the ground. If any of the last Elbow bolt holes line up with the Exit Chute attach with Bolts and Washers (possibly 2 Places). For all the holes that don't line up attach with Lag Screws and Washers.
