MICRO-EPSILON induSENSOR MSC7401 Operating Instructions Manual page 89

Anhang | Software
The entire measuring range is now symmetrically arranged around the zero point.
i
The chart is divided into 3 areas:
Green Taught-in range, limited by X
White Usable range outside the taught-in range
Red
1) Sensor designation, e.g., DTA-3G8 Custom
MSC7401 / 7802 / 7602 Miniature sensor controller for inductive displacement sensors
Optionally, you can enter the associated millimeter values which can be found under Measurement
and the additional designation Custom
Unavailable range
1 .
, X and the associated output signals.
0 2
