Installation and Assembly
Wiring
The housing must be open to connect the
see
Secondary +
Secondary -
Secondary
center tap
Primary -
Primary +
Sensor cable
shield
Fig. 12 Pin assignment for the sensor at terminal block X2, full bridge
Terminal block X2
Shield (sensor cable)
Secondary center tap
Secondary +
Secondary -
Primary +
Primary -
Fig. 13 Table of the pin assignment for the sensor at terminal block X2, full bridge
1) The colors and pins listed refer to the sensors from MICRO-EPSILON MESSTECHNIK GmbH & Co. KG.
MSC7401 / 7802 / 7602 Miniature sensor controller for inductive displacement sensors
4.3.1.
Loosen the screws.
Pass the sensor and signal cables through the cable glands.
Connect the cables to the terminals according to the pin assignments.
Magnetic core
Pin
1
2
3
4
5
6
sensors, see 4.3.3
Plunger
Cable
Braid
1
1
DTA-x-CA-x
DTA-x-LA-x
DTA-x-CR-x
C701-x
Shield
-
Gray
Gray
White
White
Brown
Black
Green
Green
Yellow
Yellow
and wire the output and power supply
Solder pin
Cable
1
1
DTA-x-TA-x
DTA-xG8-x
-
Shield
5
Gray
1
Black
2
White
3
Blue
4
Brown
cable,
