A 3.4.3.2 Zero Point - MICRO-EPSILON induSENSOR MSC7401 Operating Instructions Manual

Anhang | Software
The chart is divided into 3 areas:
Green Taught-in range, limited by X
White Usable range outside the taught-in range
Red

A 3.4.3.2 Zero Point

Fig. 81 View 1 Zero-point adjustment
MSC7401 / 7802 / 7602 Miniature sensor controller for inductive displacement sensors
Unavailable range
, X and the associated output signals.
1 2
Page 86
