Installation and Assembly
4.2.3
Fig. 6 Installation of controller
Dismantling
MSC7401 / 7802 / 7602 Miniature sensor controller for inductive displacement sensors

MSC7602 Model

If required, install a DIN rail bus connector, e.g., ME22,5 TBUS 1,5/4P1S KMGY (Phoenix:
A 1, onto the DIN rail.
If required, connect the mating plug, e.g., MCVR 1.5/5-ST-3.81 (Phoenix:
connector.
Position the MSC7602 controller on the DIN rail and press it down until it snaps
For dismantling, pull the locking element on the controller forwards, e.g., using a screwdriver
Fig. 7.
Tilt the controller in order to remove it from the DIN rail
1827156), see A
in, see Fig.
2
Fig. 7 Dismantling of controller
2
, see Fig. 7
2201732), see
1, with the bus
6.
1
1 , see
Page 21
