Anwendungsbereich / Field of application ................2 Demontage / Disassembling...................... 2 Geräteübersicht/ Device overview ..................2 Öffnen des Gerätes/ opening the device ................3 Scio Basis / Scio base ......................4 Sensormodul/ sensor module....................5 Material Liste/ list of materials ....................6 page 1 of 6...
This document is valid for the lifecycle of Scio. Scio gibt es in den Gerätevarianten/ Scio is available in following variants: Scio; Scio Four, Scio Four Oxi, Scio Four plus und Scio Four Oxi plus Demontage / Disassembling 2.1 Geräteübersicht/ Device overview...
Gummi/ rubber 20 g 3 Schrauben und Scheiben/ srews Stahl / steel 10 g and washers ! (4x) 4 Scio Basis/ Scio base (siehe weitere Demontage/ see 2570 g follow up disassembling) Gesamt/ total: 3400 g page 3 of 6...
2.3 Scio Basis / Scio base Front mit drei Schrauben lösen von dem Basisblech trennen. Separate front from the base-plate by removing three screws. Modul mit vier Schrauben vom Basisblech trennen. Separate module from the base-plate by removing four screws.
2.4 Sensormodul/ sensor module Komponenten [2] vom Modulblech trennen, hierfür zehn Kreuzschlitzschrauben lösen. Separate components [2] from the module-plate by removing ten screws. Bestandteile/ parts: Komponente/ components Material Gewicht/ weight 1 Modulblech/ modules plate Stahl/ steel 190 g 2 Komponenten (3 Teile)/ Mischschrott incl.
Material Liste/ list of materials Material/ material Gewicht Bemerkung/ note Recycling Eigenschaften/ weight recycling propertys 1. Teile die normal entsorgt werden können/ parts to dispose normal Metalle/metalls Schrauben / screws Stahl/ steel Bleche/ plates 2140 Stahl/ steel Gesamt/ total: 2,2 kg Kunststoffe/ platics Gummi / rubber Gesamt/ total: 0,14 kg...
This manual is also suitable for:
Scio fourScio four oxiScio four plusScio four oxi plus
