Hardware/Seal Kit Parts - Veeder-Root Red Jacket Quick-Set Installation, Operation And Service

Parts Lists

Hardware/Seal Kit Parts

Table 13 lists the 410154-001 Hardware/Seal Kit parts list.
(Ref. Figure)
Figure 29 on page 33
Figure 30 on page 35
Figure 30 on page 35
Figure 29 on page 33
Figure 29 on page 33
Figure 29 on page 33
Figure 29 on page 33
Figure 29 on page 33
Figure 21 on page 25
Figure 21 on page 25
Figure 30 on page 35
Figure 41 on page 47
Figure 41 on page 47
Figure 6 on page 14,
Figure 28 on page 32, and
Figure 41 on page 47
Figure 26 on page 31
Figure 41 on page 47
Appendix B
Table 13. 410154-001 Hardware/Seal Kit Parts List
Part No.
072-541-1 O-ring - 118-FKM
072-578-1 O-ring - 225-FKM
072-685-1 O-ring - 114-FKM
072-686-1 O-ring - 228-FKM
072-720-1 O-ring - 928-FKM
579005-001 O-ring - 343-FKM
579005-002 O-ring - 344-FKM
579005-003 O-ring - 345-FKM
579005-004 O-ring - 117-FKM
579005-005 O-ring - 121-FKM
579005-006 O-ring - 231-FKM
579005-007 O-ring - 014-FKM
579005-009 O-ring - 903-FKM
072-690-1 O-ring - 015-FKM
410127-001 Nut - flanged - M12x1.75-6H
579014-002 Hitch pin
577013-835 O-ring gauge
Figure 48. Hardware/Seal Kit
53
Description
rjpumps\fig52.eps
Hardware/Seal Kit Parts
Qty.
1
1
2
1
3
1
1
1
2
4
1
1
1
2
2
1
1
