TESTING THE LOOP

To ensure the installation of EK components was successful, we
recommend you perform a 24-hour leak test.
When your loop is complete and filled with coolant, connect the pump
to a PSU outside your system. Do not connect power to any of the other
components. Turn on the PSU and let the pump run continuously.
Inspect all parts of the loop, and in case the coolant leaks, fix the issue
and repeat the testing process. To prevent possible damage, please
ensure that all hardware is dry before the system is powered on.
STEP 4
M2.5X7 AX1

ATTACHING THE BACKPLATE

Place the backplate on the PCB and make sure all holes are aligned.
Position an M2.5X7 AX1 screw in each of the six (6) mounting holes
(as shown in the image) and tighten them evenly with a Phillips
head screwdriver. Do not use excessive force!
For this Step, you will need:
STEP 4
- 8 -
Phillips Head M2.5 x 7 AX1
Screwdriver 6 pcs
