EK-Quantum Vector RTX 3080/3090 Backplate Manual page 7

Backplate

Hide thumbs Also See for Vector RTX 3080/3090 Backplate:

Table of Contents

RTX™ 3080

Thermal Pad G 1.5 mm

RTX™ 3090

Thermal Pad G 1.5 mm

Thermal Pad

G 2.0mm

Thermal Pad

G 1.0 mm

Thermal Pad

G 2.0 mm

STEP 3

Once cut to size, thermal pads should be placed on the backplate,

as illustrated below.

- 7 -
