A 20 mm wrench may be necessary to hold the
handle connector/pump body in place when the
pump handle is rotated counterclockwise.
3. By hand, unscrew the hose fitting at the bottom of
the pump to remove the hose.
4. By hand, unscrew the large plastic nut located at
the top of the pump.
To make step 5 easier, remove the outer body
round end cap by unscrewing it by hand (under
the top manifold bracket). The manifold
mounting bracket can then be removed, which
gives more access to the desiccant assembly.
5. By hand, unscrew the outer body/desiccant tube
assembly from the pump base. The entire assembly
should come off of the pump base.
6. Set the assembly aside. The metal pump body is
now exposed.
Note
Note
High Pressure Pneumatic Pump
If the black pump outer body unscrews from the
clear desiccant tube, the desiccant will spill into
the pump. A strap wrench might be required at
the bottom of the desiccant tube to remove the
entire assembly.
7. Pull up and fully extend the metal pump body.
8. Apply a thin coating of the provided silicone grease
to the exposed pump shaft below the top metal
pump body.
9. To reassemble the pump, reverse these steps.
Follow the Safe Operation procedure to ensure that the
pump is in good condition.
Pump Quick Service
Note
