P5513
Pneumatic Comparison Test Pump
Users Manual
PN 3963372
November 2010
© 2010 Fluke Corporation. All rights reserved. Printed in USA. Specifications are subject to change without notice.
All product names are trademarks of their respective companies.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the P5513 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Fluke P5513

Summary of Contents for Fluke P5513

  • Page 1 Test Equipment Depot - 800.517.8431 - 99 Washington Street Melrose, MA 02176 TestEquipmentDepot.com P5513 Pneumatic Comparison Test Pump Users Manual PN 3963372 November 2010 © 2010 Fluke Corporation. All rights reserved. Printed in USA. Specifications are subject to change without notice. All product names are trademarks of their respective companies.

  • Page 3: Table Of Contents

    Table of Contents Title Page Introduction......................1 How to Contact Fluke ..................1 Safety Information ..................... 1 Safety Summary .................... 1 Compressed Gas .................... 2 Personal Protective Equipment..............2 Symbols Used in this Manual ................2 Preparation ......................2 Operating Range ....................2 Connections .......................
  • Page 4 P5513 Users Manual...
  • Page 5 List of Tables Table Title Page Symbols........................2 Test Port Insert - Parts List..................6 Screw Press Assembly - Parts List................. 9...
  • Page 6 P5513 Users Manual...
  • Page 7 List of Figures Figure Title Page Fitting Gauge Adapter.................... 3 Connect Assembly to Test Port................4 Hand Tighten Only....................4 Adjust Gauge Position.................... 5 Tighten Gauge Adapter ..................5 Hand Tighten Only....................5 Test Port Insert ....................... 6 Screw Press Assembly ................... 8 Angle Adapter ......................
  • Page 8 P5513 Users Manual...

  • Page 9: Introduction

    Introduction This manual covers the operation and maintenance of the P5513. The Pneumatic Comparison Test Pump is used for checking pressure-measuring instruments against Master Test Gauges. Note The terms ”Master Test Gauge” and “Gauge” in this document refer to any pressure-measuring instrument such as Transfer Standards, Digital Calibrators and Transducers.

  • Page 10: Compressed Gas

    The comparison test pump should be placed on a stable workbench or similar surface. Operating Range The P5513 must be connected to an external gas supply through the ¼ NPT port in the rear of the instrument case. Typically, dry Nitrogen from a commercially available compressed gas cylinder is used.

  • Page 11: Connections

    Pneumatic Comparison Test Pump Connections Connections Fit the device under test (DUT) to the test port using the method described below: W Caution Ensure that all devices are internally clean and free from contamination before connecting to the tester. Particle contamination can damage the sensitive piston assemblies, valve seats and screw pump.
  • Page 12 P5513 Users Manual 2. Screw assembly down COUNTER-CLOCKWISE on to test port. gmf02.bmp Figure 2. Connect Assembly to Test Port gmf03.bmp Figure 3. Hand Tighten Only Note Hand-tight is sufficient; ensure that the bottom face contacts the O-ring on the test port.
  • Page 13 Pneumatic Comparison Test Pump Connections gmf04.bmp Figure 4. Adjust Gauge Position 4. Hold the instrument steady, while turning the gauge adapter COUNTER-CLOCKWISE until it pulls down onto the O-ring. gmf05.bmp Figure 5. Tighten Gauge Adapter gmf06.bmp Figure 6. Hand Tighten Only...

  • Page 14: Test Port Insert

    P5513 Users Manual Test Port Insert For devices with 1/8 BSP or NPT mounting threads, the diameter of the thread is very close to the effective sealing diameter of the O-ring fitted to the test port. This can make it difficult to achieve a good seal. When mounting these devices, use the test port insert (stored in the spare seals container) as shown in Figure 7.

  • Page 15: Maintenance And Servicing

    If the system becomes contaminated with dirt or moisture, this will transfer to the reference gauge and, potentially, cause damage to it and the pressure system of the P5513. If contamination is detected, the system must be disassembled and cleaned, if left to accumulate, the control needle valves and screw press may become damaged beyond repair.
  • Page 16 P5513 Users Manual 7. If it is necessary to remove the barrel, the locknut (3) must be loosened approximately ½ turn. The barrel can then be unscrewed from the test station (1). Note It is often easier to remove the barrel support bracket to allow greater movement, (remove the 2 screws from the upper side of the top plate).

  • Page 17: Ancillary Equipment

    Pneumatic Comparison Test Pump Ancillary Equipment Table 3. Screw Press Assembly - Parts List Item Description Part TEST STATION 3921414 O RING 3864922 LOCKNUT 3921438 BARREL 3921450 SUPPORT BRACKET 3921492 O RING 3867566 ANTI-EXTRUSION RING 3919118 RAMBLER 3919129 BALL 3917855 LEAD SCREW ASSY 3885994 Ancillary Equipment...

  • Page 18: Pointer Remover/Punch, P5551

    P5513 Users Manual Pointer Remover/Punch, P5551 To remove and refit the pointer of a pressure gauge, use this tool. This tool has a spring-loaded plunger to quickly and consistently refit the pointer. gmf10.bmp Figure 10. Pointer Remover/Punch Dirt/Moisture Trap, P5532...
