- Page 1 P5510 Pneumatic Comparison Test Pump Users Manual PN 3952297 November 2010 © 2010 Fluke Corporation. All rights reserved. Printed in USA. Specifications are subject to change without notice. All product names are trademarks of their respective companies.
- Page 2 Fluke authorized resellers shall extend this warranty on new and unused products to end-user customers only but have no authority to extend a greater or different warranty on behalf of Fluke. Warranty support is available only if product is purchased through a Fluke authorized sales outlet or Buyer has paid the applicable international price.
-
Page 3: Table Of Contents
Table of Contents Title Page Introduction......................1 Operating Ranges....................1 How to Contact Fluke ..................2 Safety Information ..................... 2 Safety Summary .................... 2 Compressed Gas .................... 2 Personal Protective Equipment..............2 Symbols Used in this Manual................ 2 Connections ....................... 3 Test Port Insert.................... - Page 4 P5510 Users Manual...
-
Page 5: List Of Tables
List of Tables Table Title Page Mode and Maximum Working Pressure ..............1 Symbols........................3 Test Port Insert - Parts List..................6 Handpump Assembly - Parts List................9... - Page 6 P5510 Users Manual...
-
Page 7: List Of Figures
List of Figures Figure Title Page Fitting Gauge Adapter.................... 4 Connect Assembly to Test Port................4 Hand Tighten Only....................4 Adjust Gauge Position.................... 5 Tighten Gauge Adapter ..................5 Hand Tighten Only....................5 Handpump Assembly ..................... 9 Dirt/Moisture Trap ....................10 Angle Adapter ...................... - Page 8 P5510 Users Manual...
-
Page 9: Introduction
Introduction This manual applies to Model P5510. The Comparison Test Pump is used for checking pressure-measuring instruments against Master Test Gauges. Note The terms ”Master Test Gauge” and “Gauge” in this document refer to any pressure-measuring instrument such as Transfer Standards, Digital Calibrators and Transducers. -
Page 10: How To Contact Fluke
P5510 Users Manual How to Contact Fluke To order accessories, receive operating assistance, or get the location of the nearest Fluke distributor or Service Center, call: • Technical Support USA: 1-800-99-FLUKE (1-800-993-5853) • Calibration/Repair USA: 1-888-99-FLUKE (1-888-993-5853) • Canada: 1-800-36-FLUKE (1-800-363-5853) •... -
Page 11: Connections
Earth Ground Important Information: refer to manual Do not dispose of this product as unsorted municipal waste. Go to Fluke’s website for recycling information. Connections Fit the device under test (DUT) to the test port using the method described below:... - Page 12 P5510 Users Manual 1. Screw the appropriate gauge adapter fully on to the instrument to be tested. gla01.bmp Figure 1. Fitting Gauge Adapter 2. Screw assembly down COUNTER-CLOCKWISE on to test port. gla02.bmp Figure 2. Connect Assembly to Test Port gla03.bmp Figure 3.
- Page 13 Pneumatic Comparison Test Pump Connections Note Hand-tight is sufficient; ensure that the bottom face contacts the O-ring on the test port. 3. To adjust the position to face forward, hold the gauge adapter and turn the instrument COUNTER-CLOCKWISE, so that it faces forward. gla04.bmp Figure 4.
-
Page 14: Test Port Insert
P5510 Users Manual Test Port Insert For devices with 1/8 BSP or NPT mounting threads, the diameter of the thread is very close to the effective sealing diameter of the O-ring fitted to the test port. This can make it difficult to achieve a good seal. When mounting these devices, use the test port insert (stored in the spare seals container) as shown in Figure 7. -
Page 15: Pressure
Pneumatic Comparison Test Pump Maintenance and Servicing 1. Ensure exhaust valve is closed — Do not over tighten, as damage to the valve seat can occur. 2. To generate a vacuum in the system, use the handpump until the desired reading is reached. -
Page 16: Pump Disassembly
P5510 Users Manual 2. Remove 4 screws from sides of the housing (2 each side), and lift out cover plate from underside. 3. Disconnect nylon tubing from check valves (23) and (19). 4. Loosen locknut (3) approximately 1 turn. 5. Remove spring clip (1) from clevis (2), and swing the pump handle out of the way. 6. - Page 17 Pneumatic Comparison Test Pump Maintenance and Servicing 14 15 gla08.eps Figure 8. Handpump Assembly Table 4. Handpump Assembly - Parts List Item Description Part Item Description Part Spring Clip 3920224 Cylinder SPEC. Clevis 3920236 Bonded Seal 3918879 Locknut 3918713 O Ring 3865075 3918846 Set Screw...
-
Page 18: Ancillary Equipment
P5510 Users Manual Ancillary Equipment Dirt/Moisture Trap, P5531 Dirt/Moisture Traps provide an effective barrier against the transfer of moisture and dirt from an instrument under test to the clean pneumatic system of the comparison test pump and the master test gauge connected to it. Unexpected particle contamination or fluid inside the device under test will be prevented from entering the test system, avoiding downtime for maintenance and repair. -
Page 19: Pointer Remover/Punch, P5551
Pneumatic Comparison Test Pump Ancillary Equipment Pointer Remover/Punch, P5551 To remove and refit the pointer of a pressure gauge, use a pointer remover/punch. This tool has a spring-loaded plunger to quickly and consistently refit the pointer. gla10.bmp Figure 11. Pointer Remover/Punch... - Page 20 P5510 Users Manual...
