P5514B-70M/P5514B-70M-EP
Hydraulic Comparison Test Pump
Users Manual
April 2021
(English)
© 2021 Fluke Corporation. All rights reserved.
Specifications are subject to change without notice.
All product names are trademarks of their respective companies.
Fluke-Direct
.com
sales@GlobalTestSupply.com
1.888.610.7664
Advertisement
Table of Contents
Related Manuals for Fluke P5514B-70M
Summary of Contents for Fluke P5514B-70M
- Page 1 P5514B-70M/P5514B-70M-EP Hydraulic Comparison Test Pump Users Manual April 2021 (English) © 2021 Fluke Corporation. All rights reserved. Specifications are subject to change without notice. All product names are trademarks of their respective companies. Fluke-Direct .com sales@GlobalTestSupply.com 1.888.610.7664...
- Page 2 Fluke authorized resellers shall extend this warranty on new and unused products to end-user customers only but have no authority to extend a greater or different warranty on behalf of Fluke. Warranty support is available only if product is purchased through a Fluke authorized sales outlet or Buyer has paid the applicable international price.
-
Page 3: Table Of Contents
Table of Contents Title Page Preparation....................How to Contact Fluke Calibration.............. Safety Information ..................Specifications .................... Operating Fluid Compatibility ..............DUT Connection..................Operation ....................Priming....................Pressure Operation................Ancillary Equipment .................. Pointer Remover/Punch, P5551 ............Master Gauges ................... Fluke-Direct .com sales@GlobalTestSupply.com... - Page 4 P5514B-70M/P5514B-70M-EP Users Manual Fluke-Direct .com sales@GlobalTestSupply.com 1.888.610.7664...
-
Page 5: Preparation
The terms “Master Test Gauge” and “Gauge” in this document refer to any pressure-measuring instrument such as Transfer Standards, Digital Calibrators, and Transducers. The Fluke 700G and 2700G Digital Test Gauges are recommended for this application. This system is only as accurate as the Master Test Gauge used. The Master Test Gauge must be regularly calibrated to ensure accuracy is maintained. -
Page 6: Specifications
Specifications Pressure Range 70 MPa (10 000 psi) Pressure Connections 1/4 NPT Female (quantity 2), 1/2 NPT Female, 1/4 BSP Female, 1/2 BSP Adapters Provided Female P5514B-70M Seal Material Viton® P5514B-70M-EP Seal Ethylene Propylene Material Screw Press 20 cm (1.2 in... -
Page 7: Dut Connection
DUT/adapter assembly to the test port. Hand-tight is sufficient. 4. To adjust the position of the DUT, hold the adapter, and turn the collar clockwise 1/4-turn. 5. Position the DUT to face the desired direction, and turn the collar counter-clockwise to re- seal. Fluke-Direct .com sales@GlobalTestSupply.com 1.888.610.7664... -
Page 8: Operation
P5514B-70M/P5514B-70M-EP Users Manual Operation Priming Follow these steps: 1. Open the reservoir valve one turn counter clockwise and turn screw press fully in. 2. Close the valve and turn screw press fully out. 3. Open the valve and turn screw, press fully in. -
Page 9: Ancillary Equipment
Pointer Remover/Punch, P5551 To remove and refit the pointer of a pressure gauge, use the pointer remover/punch instrument. This tool has a spring-loaded plunger to quickly and consistently refit the pointer. See Figure 1. Figure 1. Pointer Remover/Punch Fluke-Direct .com sales@GlobalTestSupply.com 1.888.610.7664... -
Page 10: Master Gauges
Table 2. Gauges Model Nominal Specification 700G (See Figure 2) 0.05 % FS 700RG 0.04 % Reading + 0.01 % FS 2700G 0.02 % FS Figure 2. Fluke 700G PRESSURE 700G31 10K PSIG GAUGE 10K PSI 700 BAR Fluke-Direct .com sales@GlobalTestSupply.com...
