USB port connection
If you connect your PC to the MTPX Plus 128 via the USB port, and it is the first time you
have done so, the Found New Hardware Wizard opens.
1
Activate the connected USB port for your device as follows:
NOTE: If you have not installed the latest Matrix Switchers Control Program, click
Cancel and install the program.
Reconnect the switcher to the CONFIG port.
1. Select the No, not this time radio button.
2. Click Next.
The wizard installs the necessary driver to access the switcher via the CONFIG (USB)
port (this may take a few minutes).
3. On the next page that appears, select the Install the software
automatically radio button
4. Click Next.
Follow the on-screen instructions. The wizard assigns the driver necessary to access
the switcher to the connected CONFIG (USB) port (this may take a few minutes).
5. Click Finish to exit the wizard.
NOTE: You may need to repeat these steps if you subsequently connect the
switcher to a different USB port on the same computer.
Starting the program
1. Click Start > Programs > Extron Electronics >
Matrix Switchers > MATRIX Switcher +
Control Pgm.
The Comm Port Selection window appears.
2. Choose the comm (serial) port that is connected to the
switcher or IP [LAN].
NOTE: For a comm port, check the baud
rate displayed in the window. If you need
to change the baud rate, click the Baud
button and double-click the desired baud rate.
3. Click OK.
