Extron Electronics, USA
Extron Electronics, Europe
1230 South Lewis Street
Beeldschermweg 6C
Anaheim, CA 92805
3821 AH Amersfoort, The Netherlands
800.633.9876 714.491.1500
+800.3987.6673 +31.33.453.4040
FAX 714.491.1517
FAX +31.33.453.4050
www.extron.com
© 2008 Extron Electronics. All rights reserved.
Extron Electronics, Asia
Extron Electronics, Japan
135 Joo Seng Rd. #04-01
Kyodo Building, 16 Ichibancho
PM Industrial Bldg., Singapore 368363
Chiyoda-ku, Tokyo 102-0082
+800.7339.8766 +65.6383.4400
Japan
FAX +65.6383.4664
+81.3.3511.7655 FAX +81.3.3511.7656
Setup Guide
Mini Twisted Pair Matrix Switchers
MTPX Series
68-1561-01 Rev. A
06 08
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Extron electronics MTPX 1616
Summary of Contents for Extron electronics MTPX 1616
-
Page 1: Setup Guide
Extron Electronics, USA Extron Electronics, Europe Extron Electronics, Asia 1230 South Lewis Street Beeldschermweg 6C 135 Joo Seng Rd. #04-01 Anaheim, CA 92805 3821 AH Amersfoort, The Netherlands PM Industrial Bldg., Singapore 368363 800.633.9876 714.491.1500 +800.3987.6673 +31.33.453.4040 +800.7339.8766 +65.6383.4400 FAX 714.491.1517 FAX +31.33.453.4050 FAX +65.6383.4664 www.extron.com... - Page 2 Precautions Safety Instructions • English Warning Power sources • This equipment should be operated only from the power source This symbol is intended to alert the user of important indicated on the product. This equipment is intended to be used with a main power operating and maintenance (servicing) instructions in system with a grounded (neutral) conductor.
- Page 3 安全须知 • 中文 这个符号提示用户该设备用户手册中 有重要的操作和维护说明。 这个符号警告用户该设备机壳内有暴 露的危险电压，有触电危险。 注意 阅读说明书 • 用 户 使 用 该 设 备 前 必 须 阅 读 并 理 解 所 有 安 全 和 使 用 说 明 。 保存说明书 • 用户应保存安全说明书以备将来使 用。 遵守警告 • 用户应遵守产品和用户指南上的所有安 全和操作说明。...
-
Page 4: Table Of Contents
Table of Contents Chapter One • Introduction About this Manual About the MTPX Switchers Twisted Pair (TP) Cable Transmission Distance Chapter Two • Installation Rear Panel ... 2-2 Inputs ... 2-3 Outputs ... 2-4 Remote control ... 2-5 Power ... 2-5 Front Panel ... -
Page 5: Chapter One • Introduction
Table of Contents, cont’d MTPX Twisted Pair Matrix Switcher Chapter One Introduction About this Manual About the MTPX Switchers Twisted Pair (TP) Cable Transmision Distance All trademarks mentioned in this manual are the properties of their respective owners. 68-1561-01 Rev. A 06 08 MTPX •... -
Page 6: About This Manual
• MTPX 816 (8 inputs by 16 outputs) • MTPX 168 (16 inputs by 8 outputs) • MTPX 1616 (16 inputs by 16 outputs) • MTPX 1632 (16 inputs by 32 outputs) • MTPX 3216 (32 inputs by 16 outputs) •... -
Page 7: Twisted Pair (Tp) Cable Transmission Distance
Pre-Peak feature is on. For daisy-chained units, any receiver in the chain closer than 350’ (105 m) may experience some form of over- peaking when the Pre-Peak switch is on. MTPX • Introduction Refer also to the MTPX User’s Manual at www.extron.com. -
Page 8: Chapter Two • Installation
Introduction, cont’d MTPX Twisted Pair Matrix Switcher Chapter Two Installation Rear Panel Front Panel MTPX • Introduction Refer also to the MTPX User’s Manual at www.extron.com. -
Page 9: Rear Panel
MONO AUDIO OUTPUTS Figure 2-1 — MTPX 1616 rear panel The MTPX 816 and MTPX 168 are housed in the same 2U enclosureas the MTPX 1616, but have fewer input and/or output connectors to accommodate their smaller matrix sizes. LOCAL INPUTS... -
Page 10: Outputs
Installation, cont’d Outputs TP outputs — Connect up to 8, 16, or 32 (depending on the matrix size) compatible MTP receivers to the Outputs RJ-45 connectors. Local RGB (VGA) outputs — Connect one or two RGBHV video displays to the Local Outputs (VGA) 15-pin HD female connectors. -
Page 11: Creating A Tie
Installation, cont’d MTPX Twisted Pair Matrix Switcher Chapter Three Front Panel Operation Creating a Tie Saving or Recalling a Preset Setting the Front Panel Locks (Executive Modes) Defining the Audio/RS-232 Wire Pair (and Configuring the Remote Port) Viewing and Adjusting the Audio Level Viewing Ties (and Muting Outputs) MTPX •... -
Page 12: Saving Or Recalling A Preset
Front Panel Operation Creating a Tie Press and release the Esc button to clear any input LED, output LED, or control LEDs that may be lit. Press and release the Video and/or Audio I/O button(s) to select or deselect video and/or audio as desired. Lit when selected Off when deselected VIDEO AUDIO... -
Page 13: Setting The Front Panel Locks (Executive Modes)
Front Panel Operation, cont’d Setting the Front Panel Locks (Executive Modes) The matrix switcher has three levels of front panel security lock that limit the operation of the switcher from the front panel. The three levels are: • Lock mode 0 — The front panel is completely unlocked. -
Page 14: Defining The Audio/Rs-232 Wire Pair (And Configuring The Remote Port)
Front Panel Operation, cont’d Defining the Audio/RS-232 Wire Pair (and Configuring the Remote Port) To enter Configuration mode, simultaneously press and hold the Enter, Preset, View, and Esc buttons. Press and hold the Control buttons. CONTROL ENTER PRESET VIEW Release the Control buttons. CONTROL ENTER PRESET VIEW Baud... -
Page 15: Viewing And Adjusting The Audio Level
Front Panel Operation, cont’d Viewing and Adjusting the Audio Level Only the twisted pairs' input levels and only the local outputs' volume can be adjusted. Press and hold the Audio button until the Audio LED flashes. The Audio LED blinks. Hold 2 seconds AUDIO... -
Page 16: Optimizing The Video
Front Panel Operation, cont’d MTPX Twisted Pair Matrix Switcher Chapter Four Remote Control and Optimizing the Video Selected SIS Commands ™ Installing and Starting the Control Program Accessing the HTML Pages 3-10 MTPX • Front Panel Operation Refer also to the MTPX User’s Manual at www.extron.com. -
Page 17: Host-To-Switcher Instructions
Remote Control and Optimizing the Video Selected SIS ™ The switchers have Simple Instruction Set (SIS you can use for operation and configuration. You can run these commands from a PC connected to either of the switcher’s serial ports. See Host-to-switcher instructions The switcher accepts SIS (Simple Instruction Set) commands through either serial port. - Page 18 Command ASCII command (host to switcher) Create ties • Commands can be entered back-to-back in a string, with no spaces. For example: 1*1!02*02&003*003%4*24$. • The matrix switchers support 1-, 2-, and 3-digit numeric entries (1*1!, 02*02&, or 003*003%). N The & tie command for RGB and the % tie command for video can be used interchangeably. N The &...
- Page 19 Command ASCII command (host to switcher) Audio/RS-232 TP input (wire pair 3 and 6) configuration Configure input as audio Configure input as RS-232 Read TP input configuration Output pre-peaking Set output pre-peaking on Set output pre-peaking off Read output pre-peaking setting = Input number = Audio/RS-232 wire pair input type = Pre-peakable output number...
- Page 20 Command ASCII command (host to switcher) Audio or RS-232 mute commands Audio or RS-232 mute Audio or RS-232 unmute Read audio or RS-232 mute Global audio or RS-232 mute Global audio or RS-232 unmute View output mutes Example: MTPX 3216 N The “Mut”...
- Page 21 Command ASCII command (host to switcher) Save and recall presets N If you try to recall a preset that is not saved, the matrix switcher responds with the error code E11. X1$ , Save current configuration as a global preset Example: X1$ .
-
Page 22: Installing And Starting The Control Program
Remote Control and Optimizing the Video, cont’d Installing and Starting the Control Program Another way to operate the switcher, to set the skew adjustments, the level and peaking, and the output pre-peaking (see "Optimizing the video", beginning on page 4-12), is via the Windows -based Matrix Switchers Control Program. -
Page 23: Optimizing The Video
For inputs from MTP T 15HD products only — If the cable between the MTP transmitter and the MTPX Plus is > 300', turn the transmitter’s Pre-Peak switch on. For shorter cables, turn the switch off. For outputs — If the cable between the MTPX and the receiver is >...
