WARNING:
to the OFF position when completing testing and/or start-up. An alarm will
be activated if units are left in the ON position.

3.13 Wiring Diagrams

Every Data Aire evaporator, condenser, condensing unit or fluid cooler comes with a
wiring diagram.
personnel. The intent is to allow the technician to understand the wiring details
associated with the electrical components and how they interface with the controls as
well as peripheral equipment (including secondary heat exchangers).
The wiring diagram in the evaporator will indicate field interface terminals to the
secondary heat exchanger. The internal wiring of the secondary heat exchanger is
found on a separate diagram which can be found on the inside cover of the heat
exchanger electrical box.
shipping/warranty packet secured in the evaporator section.
10-2014
Do not leave the unit in manual override. Slide the switches
These diagrams are ladder type schematics intended for service
Both diagram types are also placed inside the
gForce User Manual ● 31
