WARNING:
line (provided by others) before unit start up.
condensate water will damage internal components.
Condensate pumps which ship loose, normally require a separate source of power.
Always check the pump power requirements before connecting power. Condensate
pumps are available in various voltages.
Factory installed condensate pumps are wired to display a "HIGH CONDENSATE WATER
LEVEL" alarm. The wiring for this must be done in the field on pumps that ship loose.

Condensate Probe

3.9
One (1) condensate probe for sensing water under the floor is standard and is included
with this unit. This comes in a plastic bag with about 15 feet (4.6 m) of coiled-up wire.
The condensate probe is a rectangular box that is typically placed below the unit in a
location where the water is likely to accumulate. Additional probes are available as an
option.
Place the probe flat on the floor on top of a thin layer of non-conductive silicone.
Secure the attached wires where necessary. A longer length of standard hookup wire
may be used if required.
WARNING:
and uncoil the length of wire attached to the probe will leave the unit
unprotected for sensing water under the unit and can result in a nuisance
water detected alarm. Remove/disconnect the probe if it is not to be used.

3.10 Water Sensing Cable (Optional)

Some units may be equipped with an optional water detection cable in addition to or in
lieu of the condensate probe. The cable can sense moisture anywhere along its length.
It is typically placed below the unit in a rectangular pattern that matches the perimeter
of the unit. The cable is connected to the terminal board and ready for installation.
Cable lengths will vary depending on the original order and specifications. Care should
be taken when installing the cable. Be sure the cable is not touching metal and/or any
debris under the raised floor.
10-2014
The condensate drain MUST be connected to an external drain
Failure to remove the condensate probe from the plastic bag
Without field piping
